Quick Details
-
Model:
-
5000x1490x2050
-
Passenger capacity:
-
14
-
Max. loading weight:
-
1120kgs
-
Min. ground clearance (mm):
-
135
-
Front wheel tread (mm):
-
1222
-
Rear wheel tread (mm):
-
1185
Quick Details
-
Seats:
-
11 - 20
-
Emission Standard:
-
Euro 3
-
Place of Origin:
-
Jiangsu, China
-
Model:
-
5000x1490x2050
-
Passenger capacity:
-
14
-
Max. loading weight:
-
1120kgs
-
Min. ground clearance (mm):
-
135
-
Front wheel tread (mm):
-
1222
-
Rear wheel tread (mm):
-
1185
Product Description
| Model | EG6158KF | ||
| System | 72V/5KW Series | 72V/7.5KW AC system | 72V/7.5KW AC system |
| Key Components | |||
| Battery |
12xT105 (185Ah@5hr rate) |
12xT105 (185Ah@5hr rate) |
12xT105 (185Ah@5hr rate) |
| Motor | 5KW Chinese motor for 60minutes | 72V/7.5KW AC system | 7.5KW Chinese motor |
| Controller | Curtis 1209B (400A@2minutes) |
Zapi AC2 (400A@2minute) |
Zapi AC2 (400A@2minute) |
| Performance | |||
| Passenger capacity | 14 | 14 | 14 |
| Range (loaded) based on flat road at a speed of 20km/h (km) * | >80 | >105 | >85 |
| Max. speed (km/h) | 45 | 35 | 45 |
| Minimum turning radius (m) | 5.35 | 5.35 | 5.35 |
| Max. climbing ability (loaded) | 20% | 15% | 20% |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m | ≤4m |
| Max. loading weight | 1120kgs | 1120kgs | 1120kgs |
| Net weight | 1470kgs | 1440kgs | 1460kgs |
| Dimensions | |||
| Overall dimensions (mm) | 5000x1490x2050 | ||
| Min. ground clearance (mm) | 135 | ||
| Wheelbase (mm) | 2710 | ||
| Front wheel tread (mm) | 1222 | ||
| Rear wheel tread (mm) | 1185 | ||
