Titanium exhaust tube High performance exhaust system TA9 GR7 GR11 titanium price per pound/titanium pipe price

Titanium exhaust tube High performance exhaust system TA9 GR7 GR11 titanium price per pound/titanium pipe price

FOB Reference Price: Get Latest Price

≥250 Kilograms

US $50.35

≥500 Kilograms

US $25.85

≥1000 Kilograms

US $19.86

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model Number:: TA9 GR7 GR11

Material:: titanium alloy

Outer Diameter:: OD3MM-189MM

Length:: 1-10M

Application:: industry Petrochemical Industry

Wall Thickness:: 0.5-4.5MM

Inside Diameter:: 8-80MM

Product Name:: Titanium Seamless Pipe Tube

Keywords:: Titanium Tube Metal Prices

MOQ:: 1KG

Grade:: Gr1 Gr2 TA1 TA2

Type:: Round Titanium Tube

Shape:: Round.square.Rectangle

Key Words:: Pure Seamless Titanium Tube

Density:: 4.51g/cm3

Surface:: Polished

TEST:: Nondestructive Test

Quick Details

Standard:: ASTM B338 B348 GB JIS DIN

Place of Origin:: Shandong, China

Brand Name:: MEIDE

Model Number:: TA9 GR7 GR11

Material:: titanium alloy

Outer Diameter:: OD3MM-189MM

Length:: 1-10M

Application:: industry Petrochemical Industry

Wall Thickness:: 0.5-4.5MM

Inside Diameter:: 8-80MM

Product Name:: Titanium Seamless Pipe Tube

Keywords:: Titanium Tube Metal Prices

MOQ:: 1KG

Grade:: Gr1 Gr2 TA1 TA2

Type:: Round Titanium Tube

Shape:: Round.square.Rectangle

Key Words:: Pure Seamless Titanium Tube

Density:: 4.51g/cm3

Surface:: Polished

TEST:: Nondestructive Test

Product Introduction

Product name	Titanium Seamless Tube
Material	Titanium
Standard	ASTM B337, ASTM B338. ASTM B861, ASTM B862
Shape	titanium round tube/pipe, titanium square tube/pipe titanium rectangle tube/pipe, titanium coil tube
Type	Seamless, Welded
Application	Industrial
Processing Service	Bending, Welding, Cutting, Punching
Supply Ability	10000 Set/Sets per Month
Packaging Details	Export Standard Wooden case, or can be customized

Alloy	Specifications	UTS (psi)	YS (psi)	EI (%)	RA (%)
		ksi min.	ksi min.	% min.	% min.
CP-1	ASTM B265 / B348 Grade 1	35	20	24	30
CP-2	ASTM B265 / B348 Grade 2	50	40	20	30
CP-3	ASTM B265 / B348 Grade 3	65	55	18	30
CP-4	ASTM B265 / B348 Grade 4	80	70	15	25
Ti 6AI-4V	ASTM B265 / B348 Grade 5	130	120	10	25
Ti 6AI-4v ELI	ASTM B265 / B348 Grade 23	120	110	10	15
Ti-Pd	ASTM B265 / B348 Grade 7	50	40	20	30
TiCode 12	ASTM B265 / B348 Grade 12	70	50	18	25

Grade and Chemical Composition (%) :

Grade	N	C	H	Fe	O	Al	V	Ni	Ti
Gr1	0.03	0.08	0.015	0.2	0.18	/	/	/	bal
Gr2	0.03	0.08	0.015	0.3	0.25	/	/	/	bal
Gr3	0.05	0.08	0.015	0.3	0.35	/	/	/	bal
Gr4	0.05	0.08	0.015	0.5	0.4	/	/	/
Gr5	0.05	0.08	0.015	0.4	0.2	5.5~6.75	3.5~4.5	/	bal
Gr7	0.03	0.08	0.015	0.3	0.25	/	/	/	bal
Gr9	0.03	0.08	0.015	0.25	0.15	2.5~3.5	2.0~3.0	/	bal
Gr12	0.03	0.08	0.015	0.3	0.25	/	/	0.6~0.9	bal

Mechanical property

Grade	Tensile strength(min)			Yield Strength(min)		Elongation(%)
Grade		ksi	MPa	ksi	MPa	Elongation(%)
Gr1	35	240	20	138	24
Gr2	50	345	40	275	20
Gr3	65	450	55	380	18
Gr4	80	550	70	483	15
Gr5	130	895	120	828	10

Product specification

Material: pure Titanium Tubing Size:1.5"(38.1mm)/2.0"(50.8mm)/2.5"(63.5mm) 3" (76.2mm)/3.5"(88.9mm)/4.0"(101.6mm) etc Tubing Length: 39.4 Inches (1.0 Meters) Wall Thickness: 1mm / .039" /1.2mm Style: Seamless/welding Surface: pickling surface/polish surface etc 1.Titanium straight tubing stock Seamless (SMLS) OD 38 X WT 1.0mm x L 1000mm OD 45 X WT 1.0mm x L 1000mm /OD45 X WT1.2mm x L1000mm OD 51 X WT 1.0mm x L 1000mm OD 60 X WT 1.0mm x L 1000mm OD 63 X WT 1.0mm x L 1000mm /OD63 X WT1.2mm x L1000mm/ OD63 X WT1.5 X L1000mm OD 70 X WT 1.0mm x L 1000mm OD 76 X WT 1.0mm x L 1000mm /OD76 X WT1.2mm x L1000mm/OD76X WT1.5mmx L1000mm OD 80 X WT 1.0mm x L 1000mm OD 89 X WT 1.3mm x L 1000mm Welded OD 101.6 X WT 1.0 X L 1000mm/OD 101.6 X WT 1.2 X L 1000mm OD 127.0 X WT 1.0 X L 1000mm OD 152.4 X WT 1.0 X L 1000mm etc. 2. Suit product 1)Titanium welding rod , Dia 0.8/1.0/1.2/1.5/1.6mm x L 1000mm 2)V- band clamp (2pcs titanium gr2 flange + 1pc ss304 clamp) 3) elbow or bends , 45 / 90 degree 38/45/51/60/63/76/89mm in stock 4) 2 bolts exhaust flange, 1.5"/2.0"/2.5"/2.75"/3.0"/3.5" etc 5) Pie cuts, 9 degree, tight and loose radius, 6)perforated pipe, 1.5"/2.0"/2.5"/2.75"/3.0"/3.5" etc , 2.0mm holes, staggered line and straight line; 7) titanium hanger rod, Dia 10/12/15mm x L 1000mm 8)reducer, 3" to 2"/ 3" to 2.5/ 2.5" to 2"/ 3.5" to 3.0"/3.5" to 2.5" 9)muffler, 2.5" inlet and outlet; 3.0 inlet and outlet; 3.5 inlet and outlet etc

Product application

Titanium tube application

heat exchanger, condenser tube, pipe, titanium bicycle frame, etc
Treatment process

hot forging, hot rolling, cold rolling, annealing, pickling
Surface quality

the surface is smooth and smooth, without peeling, folding, pores, cracks and other defects.
Packaging

woven bags, plastic foam, cartons, wooden cases, etc. shall be used according to the specifications of the goods. The packaging meeting the transportation standards ensures all safety during transportation.

FAQ

1.Are you a manufacturer or a trader?
We're a manufacturer with more than years of professional production experience.
2.Can you accept OEM?
Yes, OEM is acceptable. Just pls provide us with the drawing or sample, we will production totally according to your requirements.
3.Can you provide us with the design drawing?
Yeah, of course, we will provide you with the drawing after you paid or prepaid.

4. Can your factory produce products according to our drawings?

Yes, we can. Most products can be customized, including the Logo on products.
5.What kind of your packaging?
Neutral plywood or wooden box packaging or according to customer's requirements.
6.How long is your delivery time?
Normally 30days after payment, and we promise we will deliver as soon as we can.
