Quick Details
-
Model Number:
-
TW-10NEO
-
Dimension:
-
(W*H*D):500*294*430 mm
-
Power Supply Mode:
-
Power Amplifer/ Mixer/AC
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
350W
-
Shell Material:
-
Plywood
-
Format:
-
Other
-
The body material:
-
Plywood Wood Cabient
-
Product Name:
-
Passive 10 Inch Line Array Speaker
-
Components:
-
10 Inch Baritone*1 piece/1.75 Inch Tweeter*2
-
Feature:
-
TW-10 ( Neodymium magnet Updated Version)
-
MF Rated Power:
-
350W AES
-
HF Rated Power:
-
150W AES
-
MF Sensitivity(1W/M):
-
104dB
-
HF Sensitivity(1W/M):
-
114dB
-
Rated Maximum SPL:
-
135dB peak,@1m
-
Frequency Response:
-
65Hz~18KHz (±3dB)
-
Coverage Angle (1KHz):
-
120°H * 20°V
Quick Details
-
Warranty:
-
3years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MORIN
-
Model Number:
-
TW-10NEO
-
Dimension:
-
(W*H*D):500*294*430 mm
-
Power Supply Mode:
-
Power Amplifer/ Mixer/AC
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
350W
-
Shell Material:
-
Plywood
-
Format:
-
Other
-
The body material:
-
Plywood Wood Cabient
-
Product Name:
-
Passive 10 Inch Line Array Speaker
-
Components:
-
10 Inch Baritone*1 piece/1.75 Inch Tweeter*2
-
Feature:
-
TW-10 ( Neodymium magnet Updated Version)
-
MF Rated Power:
-
350W AES
-
HF Rated Power:
-
150W AES
-
MF Sensitivity(1W/M):
-
104dB
-
HF Sensitivity(1W/M):
-
114dB
-
Rated Maximum SPL:
-
135dB peak,@1m
-
Frequency Response:
-
65Hz~18KHz (±3dB)
-
Coverage Angle (1KHz):
-
120°H * 20°V
Product Paramenters
|
Product Name
|
Passive 10 Inch Line Array Speaker
|
|
|
|
|||
|
Model Name
|
TW-10
|
|
|
|
|||
|
Type
|
Passive
|
|
|
|
|||
|
Feature
|
Model TW-10 Neodymium magnet Updated Version
|
|
|
|
|||
|
Speaker Unit - LF
|
No
|
|
|
|
|||
|
Speaker Unit - MF
|
10 Inch Baritone * 1 Piece
|
|
|
|
|||
|
Speaker Unit - HF
|
1.7 Inch Tweeter * 2 Pieces
|
|
|
|
|||
|
Enclosure Material
|
Plywood
|
|
|
|
|||
|
MF Rated Power(w)
|
350W AES
|
|
|
|
|||
|
HF Rated Power(w)
|
150W AES
|
|
|
|
|||
|
MF Sensitivity(1W/M)
|
104dB
|
|
|
|
|||
|
HF Sensitivity(1W/M)
|
114dB
|
|
|
|
|||
|
Rated Maximum SPL
|
135dB peak,@1m
|
|
|
|
|||
|
Frequency Response
|
65Hz～18KHz (±3dB)
|
|
|
|
|||
|
Coverage Angle (1KHz)
|
120°H×20°V
|
|
|
|
|||
|
Product Size(mm)
|
(W*H*D):500*294*430 mm
|
|
|
|
|||
|
Net Weight(kg)
|
20kg
|
|
|
|
|||
