- Product Details
- {{item.text}}
Quick Details
-
Experience:
-
Alibaba the 20th year golden supplier
-
Certificate:
-
CE/ISO approved
-
Clients:
-
supermarket, retail store , chain store
-
Specification:
-
Full range of EAS products
-
Design Ability:
-
50+ models EAS label
-
Color:
-
White,barcode or Customized
-
Function:
-
stable and high sensitive
-
Characteristic:
-
Compatible with all 58/66KHZ AM System
-
Material:
-
Paper
-
Supply Ability:
-
2000,000 Piece/Pieces per day ,samples available
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
HIGHLIGHT
-
Model Number:
-
AL001
-
Experience:
-
Alibaba the 20th year golden supplier
-
Certificate:
-
CE/ISO approved
-
Clients:
-
supermarket, retail store , chain store
-
Specification:
-
Full range of EAS products
-
Design Ability:
-
50+ models EAS label
-
Color:
-
White,barcode or Customized
-
Function:
-
stable and high sensitive
-
Characteristic:
-
Compatible with all 58/66KHZ AM System
-
Material:
-
Paper
-
Supply Ability:
-
2000,000 Piece/Pieces per day ,samples available
Introduction of EAS AM label:
EAS AM label is sticked on the commodity which is not easy to be attached with a hard tag. And EAS AM label will be deactivated by the deactivator at the cashier after customer pay for the commodity. Deactivation of EAS AM label is also dependent on the size of the label and the power of the deactivation pad (the larger the label, the greater the field it generates for deactivation to take place. For this reason very small labels can cause issues for consistent deactivation).
Advantage of the AL001 EAS AM label
Frequency : 58kHz+/-300Hz
Deactivation : 100%
Operating Distance: Up to 1.6m for Dual Pedestal System
AQL = 1.0
CE/ ISO/ RoHS/ MSDS
Specification for retail security EAS AM label
|
Dimension for EAS AM label/ AM sticker |
|
|
Length |
45.21 mm(±0.5mm) |
|
Width |
10.67mm(±0.5mm) |
|
Thickness |
≤ 1.89mm |
|
Applicable environment |
|
|
Temperature |
The maximum storage temperature is 65°C |
|
Humidity |
Temperature 65 ℃ , humidity 80% can be stored for up to 96 hours |
|
Storage period |
It can be stored for one year at a temperature of 15°C-32°C and a humidity of 50-70%. |
|
Under pressure |
At room temperature, the average force can withstand a maximum pressure of 445N |
|
External Magnetic Field |
≤ 8 Gauss |
|
Packing Specifications |
|
|
Quantity for each sheet |
108 pieces |
|
Smallest packaging |
5000pcs/box, 285mm*210mm*110mm |
|
Weight per box |
2.89kg |
|
Label Application Guidelines |
|
|
Should be posted within 7cm from the barcode |
|
|
Should be placed where it is not easy to find |
|
|
Avoid product descriptions |
|
|
No direction required for label posting |
|
|
In order to ensure that the label can be used effectively, please place the label at a distance of ≥ 3mm from non-ferrous metals and ≥ 9mm from ferrous metals |
|
FAQ
1. Q: How to choose the right EAS label?
A: Firstly, the frequency of EAS label must be same with the frequency of the EAS antenna at the entrance.
Secondly, try to choose EAS label in large size. The bigger size, the better detection.
2. Q: How about the color on the EAS AM label?
A: 3 colors: barcode, black and white. Barcode one is the most popular one.
3. Q: Can we scan the barcode on the EAS 58KHz label to get product info such as price, name...?
A: No. the barcode is fake..
4. Q: How about the package for EAS AM label?
A: 108pcs/plate, 47 plates/ inner carton, 20000pcs in one carton.
Customized package is available for bulk order.
5. Q: What is the difference of deactivable EAS label and non-deactivable EAS label?
A: Deactivable EAS label is disposable (one-time used). Non-deactivable EAS label is reusable and often stick in the safer boxes.
6. Q: What is the certification for your EAS AM label?
A: EAS AM label is CE/ ISO/ RoHS/ MSDS certificated.
7. How can i contact you now?
Contact us, and we will show you a professional and excellent partner.
