Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
BEWELL
-
Model Number:
-
BM-F100
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
1088*554.5*3mm/±0.5%
-
Output Port:
-
MC4( Cam be customized)
-
Material:
-
ETFE+EVA+Mono Cell+EVA+TPT+EVA+PET
-
Operating Temperature:
-
-20℃~60℃
-
Certificate:
-
CE, FCC
Quick Details
-
Cell size:
-
166*166mm
-
Type:
-
Flexible
-
Panel Efficiency:
-
up to 23%
-
Warranty:
-
1 year
-
Brand Name:
-
BEWELL
-
Model Number:
-
BM-F100
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
1088*554.5*3mm/±0.5%
-
Output Port:
-
MC4( Cam be customized)
-
Material:
-
ETFE+EVA+Mono Cell+EVA+TPT+EVA+PET
-
Operating Temperature:
-
-20℃~60℃
-
Certificate:
-
CE, FCC
Product Description
Specification
|
Product Model NO.
|
BM-F100
|
BM-F120
|
BM-F200
|
||
|
Cell Type
|
Mono(166*166mm)
|
Mono(166*166mm)
|
Mono(166*166mm)
|
||
|
Material
|
ETFE+EVA+Mono Cell+EVA+TPT+EVA+PET
|
|
|
||
|
Rated Power
|
100W
|
120W
|
200W
|
||
|
Vmp
|
18V
|
21.7V
|
18V
|
||
|
Imp
|
5.5A
|
5.8 A
|
11.11A
|
||
|
Voc
|
21.6V
|
27V
|
21.6V
|
||
|
Conversion Efficiency
|
Up to 23%
|
21%-23.5%
|
21.9％～23.4％
|
||
|
Output Port
|
MC4 Compatible Connector（ Can be customized）
|
|
|
||
|
Total transmittance
|
80%~85%
|
|
|
||
|
Tolerance
|
±5%
|
|
|
||
|
Unfolded Size(CM)
|
1088*554.5*3mm/±0.5%
|
1022*707*3mm/±0.5%
|
1088*554.5*3mm/±0.5%
|
||
|
Warranty
|
1 Year
|
|
|
||
Details Images
Product Usage
Packing&Shipping
Below is package of solar panel for reference.
Certifications
Related Products
Company Introduction
Wenzhou Bewell New Energy Co., Ltd. has been focusing on the research and development, production, and sales of renewable energy and electric power equipment such as solar inverters and energy storage series for a long time, and has now developed several series of inverter products, with the power ranging from 150w to10,000W.
With different parameter settings, it can meet the requirements of different scenarios of use, such as commercial, indoor, and outdoor construction, mobile office, automobile, ship, etc.
