Name: Front to rear design
Brand: JIN ZHI YIN
Original: China
Front to rear design , suitable for large materials.
- Product Details
- {{item.text}}
Quick Details
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, PLT
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JINZHIYIN
-
Weight (KG):
-
180 KG
-
Configuration:
-
CO2 laser tube
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
CO2 Laser Engraving Machine Laser cutting machine cnc laser engraver
-
Software:
-
Coreldraw corellaser
-
Power Voltage:
-
AC 110 or 220V 50-60HZ
-
Computer system:
-
Windows XP/win7/ win8/win10
-
cooling way:
-
water cooling and protect system
-
Position system:
-
Red-dot sensor
-
Table:
-
Honeycomb
-
Color:
-
Orange and Grey
-
Cutting Speed:
-
0-3600mm/min
Quick Details
-
Engraving Area:
-
600*900mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
0-24000mm/min
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, PLT
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JINZHIYIN
-
Weight (KG):
-
180 KG
-
Configuration:
-
CO2 laser tube
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
CO2 Laser Engraving Machine Laser cutting machine cnc laser engraver
-
Software:
-
Coreldraw corellaser
-
Power Voltage:
-
AC 110 or 220V 50-60HZ
-
Computer system:
-
Windows XP/win7/ win8/win10
-
cooling way:
-
water cooling and protect system
-
Position system:
-
Red-dot sensor
-
Table:
-
Honeycomb
-
Color:
-
Orange and Grey
-
Cutting Speed:
-
0-3600mm/min
Products Description
Parts 1
Parts 2
Name: Ruida 6442s controller
Brand: RUIDA Technology
Original: China
Ruida 6442s controller have many features.
1, support for multiple languages
2, support color layering
3, support offline work
4, support carving and cutting simultaneously
5, support for size compensation
Brand: RUIDA Technology
Original: China
Ruida 6442s controller have many features.
1, support for multiple languages
2, support color layering
3, support offline work
4, support carving and cutting simultaneously
5, support for size compensation
Parts 3
Name: Y-Axis Double linear guide rail
Brand: China famous brand
Original: China
Drive system with high precision linear guide and slide block, high precision, wear resistance, small resistance, high speed,small
noise.
Brand: China famous brand
Original: China
Drive system with high precision linear guide and slide block, high precision, wear resistance, small resistance, high speed,small
noise.
Parts 4
Name: Laser tube
Brand: Reci brand or EFR Brand
Original: China
EFR Laser tube 60w/80w/100w optional ( glable warranty 12 months,6000 hour work life-span )
Reci brand laser tube optional ( 10000 hours work life-span ). 80w w1 / 100w w2 tube optional
Brand: Reci brand or EFR Brand
Original: China
EFR Laser tube 60w/80w/100w optional ( glable warranty 12 months,6000 hour work life-span )
Reci brand laser tube optional ( 10000 hours work life-span ). 80w w1 / 100w w2 tube optional
Main Features:
1) Ruida 6442s controller, the most popular control system for co2 laser engraving cutting machine
2) Front to rear design, suitable for large materials
3) EFR Laser tube ( glable warranty 12 months,6000 hour work life-span ) or Reci laser tube optional ( 10000 hours work life-span
4) Electrical up and down blade work table, 600mm*900mm work area, lift distance 180mm
5) 12 Months warranty + all life teach support + 16 hours online service .
6) Y-Axis double linear square guide rail + big power motor, small noise, fast speed, max is 700mm/s
2) Front to rear design, suitable for large materials
3) EFR Laser tube ( glable warranty 12 months,6000 hour work life-span ) or Reci laser tube optional ( 10000 hours work life-span
4) Electrical up and down blade work table, 600mm*900mm work area, lift distance 180mm
5) 12 Months warranty + all life teach support + 16 hours online service .
6) Y-Axis double linear square guide rail + big power motor, small noise, fast speed, max is 700mm/s
Accessories
|
Specification for 6090 laser engraving cutting machine
|
|
|
|
|
||||
|
|
Laser power
|
EFR tube ( 60w/80w/100w) or Reci w2 tube 100w
|
|
|
||||
|
|
Controller
|
Ruida 6442s controller ( Rdworks v8 )
|
|
|
||||
|
|
Guide rail
|
Y-Axis double linear guide rail
|
|
|
||||
|
|
Work table
|
Honey comb table +blade work table ( electrical up and down ,lifting distance 180mm )
|
|
|
||||
|
|
Engraving speed
|
0-1000mm/s
|
|
|
||||
|
|
Cutting speed
|
0-700mm/s
|
|
|
||||
|
|
Support Fils
|
BMP,HPGL,PLT,DST and AI etc.
|
|
|
||||
|
|
Resolution
|
±0.05mm/1000DPI
|
|
|
||||
|
|
Minimum Letter
|
English 1×1mm (Chinese Characters 2*2mm)
|
|
|
||||
|
|
Position system
|
Red dot position
|
|
|
||||
|
|
Power Voltage
|
AC 110 or 220V±10%,50-60Hz
|
|
|
||||
|
|
Power cable
|
European Type/China Type/America Type/UK Type
|
|
|
||||
|
|
Cooling way
|
Water cooling and protection system
|
|
|
||||
|
|
Machine Size
|
178*110*89cm
|
|
|
||||
|
|
Gross Weight
|
185kgs
|
|
|
||||
|
|
Package
|
Standard plywood case for export
|
|
|
||||
|
|
Warranty
|
All life free tech support, 3 year warranty, except consumables
|
|
|
||||
|
Free accessories
|
Air Compressor/Water Pump/Air Pipe/Water Pipe/Software and Dongle/ English User Manual/USB Cable/Power Cable
|
|
|
|
||||
Packaging:
Whole film packaging machine; anti-collision package edge; fumigation-free plywood wooden box and pallets with iron binding belt.
Shipping:
We cooperate with the company whose experience in the ocean transportation will guarantee your machine safety. We also provide train transport, especially to Russia, Ukraine and other inland countries.
Whole film packaging machine; anti-collision package edge; fumigation-free plywood wooden box and pallets with iron binding belt.
Shipping:
We cooperate with the company whose experience in the ocean transportation will guarantee your machine safety. We also provide train transport, especially to Russia, Ukraine and other inland countries.
