Quick Details
-
Brand Name:
-
THLB
-
Model Number:
-
3650
-
Place of Origin:
-
Shandong, China
-
Weight:
-
20kg, 20kg
-
The charging ratio:
-
DOD100%
-
The discharge rate:
-
DOD100%
-
Battery type:
-
Rechargeable Li-ion Battery
-
Nominal Capacity:
-
48Ah
-
Nominal Voltage:
-
38.4V
-
Cycle life:
-
2000 Times 80% DOD
-
Warranty:
-
3 Years
-
OEM/ODM:
-
Available
-
Battery cell:
-
18650 1600ah 12S32P
-
Brand:
-
New(grade A cell)
-
Size:
-
310*180*234mm
Quick Details
-
Storage Type:
-
Ambiant Temperature Storage
-
Anode Material:
-
LFP
-
Application:
-
Toys, Home Appliances, Consumer Electronics, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
-
Brand Name:
-
THLB
-
Model Number:
-
3650
-
Place of Origin:
-
Shandong, China
-
Weight:
-
20kg, 20kg
-
The charging ratio:
-
DOD100%
-
The discharge rate:
-
DOD100%
-
Battery type:
-
Rechargeable Li-ion Battery
-
Nominal Capacity:
-
48Ah
-
Nominal Voltage:
-
38.4V
-
Cycle life:
-
2000 Times 80% DOD
-
Warranty:
-
3 Years
-
OEM/ODM:
-
Available
-
Battery cell:
-
18650 1600ah 12S32P
-
Brand:
-
New(grade A cell)
-
Size:
-
310*180*234mm
Product Description
Factory hot sale new lifepo4 36v battery pack lithium ion power storage system
1. Longer cycle lifespan
2. Smaller and lighter
3. With more energy, it can provide more current
4. Higher & lower temperature are more adaptable
5. More environmentally friendly
6. Longer warranty
Notes:
38.4V 48Ah is designed & developed for customer, private mold, parameters are only for reference. If you have customized requirements, please feel free to contact us.
Specification
|
One Battery module
|
50Ahr or 1920Whr (384 pcs 18650 1.6Ah cells in a
12s32p configuration.) |
|
Nominal module voltage
|
38.4V
|
|
Maximum module voltage
|
43.8V
|
|
Minimum module voltage
|
30.0V
|
|
Nominal load current
|
96A max. continuous current @ 23° C
|
|
Peak load current
|
140A max for 30 sec @ 23° C
|
|
Charge Disconnect
|
When the Battery modules are charged to full, they will
communicate with BMU, and the BMU has the capability to turn off the charger or open the main contactor. The battery module itself does not have any switch to disconnect the charger. |
|
Size
|
310 mm x 180mm x 234 mm
|
|
Terminals, Female Threaded
|
M8*1.25
|
|
Weight
|
20 kg
|
