Quick Details
-
Brand Name:
-
synmot
-
Model Number:
-
SM-80A75B30C-EN31N
-
Frequency:
-
50/60HZ
-
Product Name:
-
Servo motor with gear pump for hydraulics systems
-
Motor Power:
-
0.75kW
-
Drive Power:
-
0.75kW
-
Motor Speed:
-
3000rpm
-
Motor Torque:
-
2.4N.m
-
Voltage:
-
220V
-
Motor frame:
-
80MM
-
Customize:
-
Yes
-
Certification:
-
CE /ISO 9001/2008
Quick Details
-
AC Voltage:
-
380 / 480 V
-
Warranty:
-
1year
-
Place of Origin:
-
China, Ningbo Zhejiang Province
-
Brand Name:
-
synmot
-
Model Number:
-
SM-80A75B30C-EN31N
-
Frequency:
-
50/60HZ
-
Product Name:
-
Servo motor with gear pump for hydraulics systems
-
Motor Power:
-
0.75kW
-
Drive Power:
-
0.75kW
-
Motor Speed:
-
3000rpm
-
Motor Torque:
-
2.4N.m
-
Voltage:
-
220V
-
Motor frame:
-
80MM
-
Customize:
-
Yes
-
Certification:
-
CE /ISO 9001/2008
Product Image
Other explosions
Synmot electro-hydraulic servo systems are highly integrated systems with the perfect mating of pump, motors and drives. It can achieve precise flow and pressure control and the dynamic response is fast. Synmot electric-hydraulic servo systems support multi pump confluence with excellent energy-saving performance and simple maintenance.
Product Detail
| Model | Motor Power | Motor torque | Motor Speed | Drive power | Servo Motors | Servo drive |
| kW | N.m | rpm | kW | |||
|
400W Servo System |
0.4 | 1.3 | 3000 | 0.75 | SM-60A40B30C-EN31N | SM10-75BB-0ER |
| 750W servo system | 0.75 | 2.4 | 3000 | O.75 | SM-80A75B30C-EN31N | SM10-75BB-0ER |
| 1 KW servo system | 1 | 3.8 | 2500 | 1 | SM-110A10C25C-EN31N | SM10-10CB-0ER |
| 1 KW servo system | 1 | 4.8 | 2000 | 1 | SM-130A10C20C-EN31N | SM10-10CB-0ER |
| 1.5KW servo system | 1.5 | 7.2 | 2000 | 1.5 | SM-130A15C20C-EN31N | SM10-15CC-0ER |
| 2.3KW servoSystem | 2.3 | 14.7 | 1500 | 2.3 | SM-130A23C15C-EN31N | SM10-23CC-0ER |
| 3KW servo system | 3 | 21 | 1500 | 3 | SM-190H30C15C-EN31N | SM10-30CC-0ER |
| 7.5KW servo system | 7.5 | 35 | 2000 | 7.5 | SM-190H75C20C-EN31N | SM10-75CC-0ER |
| 21Kw servo system | 21KW | 118 | 1700 | 21KW | SM-200H21D17C-EN31N | SM22-21DC-0ER |
| 37Kw Servo System | 37KW | 208 | 1700 | 37KW | SM-260H37D17C-EN31N | SM22-37DC-OER |
Specification of Servo System :
