- Product Details
- {{item.text}}
Quick Details
-
Type:
-
Air Source Heat Pump
-
Storage / Tankless:
-
storage
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Power World/ OEM
-
Model Number:
-
PW040-DKZLRS-E/S
-
Condensor:
-
High efficient tank
-
COP:
-
4.8
-
Compressor:
-
Pana-sonic
-
Function:
-
Sanitary hot water, heating, cooling
-
NW:
-
115kg
-
Refrigerant:
-
R290
-
Keyword:
-
EVI Inverter Heat Pump
-
Max Hot Water Temperature:
-
75C
-
Material:
-
Galvanized Metal
-
Heat source:
-
Air Source 75%+electricity25%
Quick Details
-
Warranty:
-
2 years
-
Application:
-
Outdoor, Hotel, Commercial, Household
-
Power Source:
-
Electric
-
Type:
-
Air Source Heat Pump
-
Storage / Tankless:
-
storage
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Power World/ OEM
-
Model Number:
-
PW040-DKZLRS-E/S
-
Condensor:
-
High efficient tank
-
COP:
-
4.8
-
Compressor:
-
Pana-sonic
-
Function:
-
Sanitary hot water, heating, cooling
-
NW:
-
115kg
-
Refrigerant:
-
R290
-
Keyword:
-
EVI Inverter Heat Pump
-
Max Hot Water Temperature:
-
75C
-
Material:
-
Galvanized Metal
-
Heat source:
-
Air Source 75%+electricity25%
Products Description
LOW GWP R290 REFRIGERANT
MULTIFUNCTIONAL
HEAT PUMP
The perfect performance of the R290 FULL DC INVERTER Heat Pump can meet the user's needs of house heating, cooling and domestic hot water throughout the year ( by 3-way valve):
*Domestic Hot Water Only
*Cooling Only
*Heating Only
*Heating+ DHW (Priority)
*Cooling+ DHW (Priority)
STABLE AND RELIABLE
OPERATE AT -25℃
Under low ambient temperature, the performance, heating ability and operational stability of normal heat pumps will be limited. Power World's R290 FULL DC INVERTER heat pump can operate stably and efficiently in extremely cold regions of -25℃ without EVI technology, maintaining a high COP and outputting 75℃ hot water to ensure the heating and cooling of the house need.
Reliable operation in extreme temperatures of -25°C, Powerful heating can output 75°C hot water
FULL INVERTER TECHNOLOGY
The Full DC inverter technology makes the unit can intelligently adjust the operating frequency and control the water temperature to keep the room at a constant-temps. It can save up to 50% energy electricity compared to ON-OFF units and up to 75% energy compared to traditional boiler electric heat pumps.
DC Inverter Panasonic Compressor, Stepless DC Inverter Fan Motor, DC Inverter Water Circulation Water Pump
LCD CONTROL PANEL AND WI-FI APP
5-Inches large LCD touch screen control panel and “Smart Life” Wi-Fi App support local language +English options. This user-friendly design reduces users' foreign language dyslexia, and also facilitates distributors to expand their market locally.
FOUR OPERATING MODES SAVE YOUR ENERGY
Based on the different needs of users, Power World has developed 4 operating modes: Powerful Mode, Smart Mode, Silent Mode, Vacation Mode. Users can choose modes with different operating frequencies according to actual needs, which help users save a lot of electricity bills.
R290 FULL DC INVERTER Heat Pump has passed the ERP A+++ energy class test of TUV. Its energy efficiency grade can not only reach A+++ at 35°C, but also A+++ at 55°C. In addition, its SCOP can be as high as 4.86,
which ensures the perfect performance and ultra-high energy efficiency of the unit.
The unit uses a special three-layer sound insulation cotton, combined with Power World's multiple noise reduction technology, so that the unit can run smoothly and quietly
without mechanical noise.
IoT Platfrom
|
DC Inverter Heat Pump for cooling heating and DHW （R290）
|
|
|
|
|
|
|
||||||
|
Model
|
PW030-DKZLRS-E/S
|
PW040-DKZLRS-E/S
|
PW050-DKZLRS-E/S
|
PW040-DKZLRS-E
|
PW050-DKZLRS-E
|
PW060-DKZLRS-E
|
||||||
|
Heating Condition - Ambient Temp.（DB/WB）: 7/6℃，Water Temp.（In/Out）：30/35℃
|
|
|
|
|
|
|
||||||
|
Heating Capacity Range (kW)
|
3.2~9.0
|
4.2~11.8
|
5.6~16.0
|
4.2~11.8
|
5.6~16.0
|
7.7~22.0
|
||||||
|
Heating Power Input Range(kW)
|
0.68~2.18
|
0.88~2.83
|
1.16~3.80
|
0.88~2.83
|
1.16~3.80
|
1.58~5.23
|
||||||
|
COP Range
|
4.13~4.71
|
4.17~4.75
|
4.21~4.83
|
4.17~4.75
|
4.21~4.83
|
4.21~4.86
|
||||||
|
DHW Condition-Ambient Temp.（DB/WB）: 7/6℃，Water Temp.（In/Out）：15/55℃
|
|
|
|
|
|
|
||||||
|
Heating Capacity Range (kW)
|
2.5~7.2
|
3.3~9.4
|
4.5~12.8
|
3.3~9.4
|
4.5~12.8
|
6.2~17.6
|
||||||
|
Heating Power Input Range(kW)
|
0.65~2.14
|
0.86~2.76
|
1.15~3.70
|
0.86~2.76
|
1.15~3.70
|
1.57~5.06
|
||||||
|
COP Range
|
3.37~3.82
|
3.41~3.85
|
3.46~3.92
|
3.41~3.85
|
3.46~3.92
|
3.48~3.96
|
||||||
|
cooling Condition - Ambient Temp.（DB/WB）:35/24℃，Water Temp.（In/Out）：12/7℃
|
|
|
|
|
|
|
||||||
|
Cooling Capacity Range (kW)
|
2.1~5.8
|
2.9~8.2
|
4.5~12.8
|
2.9~8.2
|
4.5~12.8
|
5.4~15.3
|
||||||
|
Cooling Power Input Range(kW)
|
0.69~2.19
|
0.95~3.07
|
1.45~4.72
|
0.95~3.07
|
1.45~4.72
|
1.73~5.60
|
||||||
|
EER Range
|
2.65~3.04
|
2.67~3.06
|
2.71~3.10
|
2.67~3.06
|
2.71~3.10
|
2.73~3.12
|
||||||
|
ErP Level (35°C)
|
A+++
|
A+++
|
A+++
|
A+++
|
A+++
|
A+++
|
||||||
|
Refrigerant
|
R290
|
|
|
|
|
|
||||||
|
Power supply
|
230V/1Ph/50Hz/60Hz
|
|
|
380V/3Ph/50-60Hz
|
|
|
||||||
|
Diameter of pipe (mm)
|
DN25
|
DN25
|
DN25
|
DN25
|
DN25
|
DN25
|
||||||
|
Max water head (m）
|
9
|
9
|
12
|
9
|
12
|
12
|
||||||
|
Noise dB(A)
|
≤47
|
≤50
|
≤52
|
≤50
|
≤52
|
≤53
|
||||||
|
Net Weight (kg)
|
105
|
115
|
160
|
115
|
160
|
165
|
||||||
|
Net Dimension (L/W/H) mm
|
970×475×820
|
1080×475×970
|
1050×480×1380
|
1080×475×970
|
1050×480×1380
|
1050×480×1380
|
||||||
|
Operation Ambient Temp. (℃)
|
-25~43℃
|
|
|
|
|
|
||||||
|
Operating water temperature (℃)
|
20~65℃（DHW ）
|
|
|
|
|
|
||||||
|
Operating water temperature (℃)
|
20~70℃（Heating）
|
|
|
|
|
|
||||||
|
Operating water temperature (℃)
|
7~35℃（Cooling）
|
|
|
|
|
|
||||||
