Product Features
Support ITU-T G.984.2 GPON OLT C++ Enhanced application
Single fiber bi-directional data links with symmetric 2.488Gbps Tx and 1.244Gbps Rx
1490nm continuous-mode transmitter with DFB LD
1310nm burst-mode receiver with APD-TIA
2-wire interface for integrated digital diagnostic Monitoring
Receiver RESET, Signal Detect, RSSI function indication (RESET, RX_SD, RSSI)
SFP package with SC/UPC receptacle optical interface
Single +3.3V power supply
Operation case temperature 0~70°C
RoHS6 compliance
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
APT
-
Use:
-
FTTB/FTTH/FTTX
-
Warranty Time:
-
5 YEARS
-
Certification:
-
CE, ISO, RoHS, GS
-
Port Speed:
-
155m/1.25g/2.5g/10g/25g/40g/100g
-
Transmission Distance:
-
3km/10km/20km/40km/60km/80km/100km/120km/160km
-
Wavelength:
-
Tx1490nm/Rx1310nm
-
Power out:
-
7dBm
-
Fiber Type:
-
Single Fiber Single Mode
-
Connector:
-
SC/LC
-
Commercial Temperature Range:
-
0°C to 70°C
-
Voltage Supply:
-
3.3V
-
Moq:
-
2
Quick Details
-
Type:
-
Testers &Tools
-
Model Number:
-
APTSFP
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
APT
-
Use:
-
FTTB/FTTH/FTTX
-
Warranty Time:
-
5 YEARS
-
Certification:
-
CE, ISO, RoHS, GS
-
Port Speed:
-
155m/1.25g/2.5g/10g/25g/40g/100g
-
Transmission Distance:
-
3km/10km/20km/40km/60km/80km/100km/120km/160km
-
Wavelength:
-
Tx1490nm/Rx1310nm
-
Power out:
-
7dBm
-
Fiber Type:
-
Single Fiber Single Mode
-
Connector:
-
SC/LC
-
Commercial Temperature Range:
-
0°C to 70°C
-
Voltage Supply:
-
3.3V
-
Moq:
-
2
Product Description
Optical modules are optoelectronic devices that perform photoelectric and electro-optical conversion. The transmitting end of the optical module converts the electrical signal into an optical signal, and the receiving end converts the optical signal into an electrical signal. Optical modules are classified according to the package form, and the common ones are SFP, SFP+, SFF, Gigabit Ethernet Interface Converter (GBIC), etc.
Feature
Specification
|
item
|
value
|
|
Model Number
|
APTSFP
|
|
Type
|
Testers &Tools
|
|
Place of Origin
|
China
|
|
|
Shandong
|
|
Brand Name
|
APT
|
|
Use
|
FTTB/FTTH/FTTX
|
|
Warranty Time
|
5 YEARS
|
|
Network
|
Wireless Lan, bluetooth, Wired LAN, ONVIF, SDK, TCP, Ip, POE, GPRS, wifi, 4g, GSM, 3G, Wiegand
|
|
Certification
|
CE, ISO, RoHS, GS
|
|
Port Speed
|
155m/1.25g/2.5g/10g/25g/40g/100g
|
|
Transmission Distance
|
3km/10km/20km/40km/60km/80km/100km/120km/160km
|
|
Wavelength
|
Tx1490nm/Rx1310nm
|
|
Power out
|
7dBm
|
|
Fiber Type
|
Single Fiber Single Mode
|
|
Connector
|
SC/LC
|
|
Commercial Temperature Range
|
0°C to 70°C
|
|
Voltage Supply
|
3.3V
|
|
Moq
|
2
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
