Quick Details
-
Place of Origin:
-
Henan, China
-
Product name:
-
1700 degree muffle furnace
-
Max temperature:
-
1700 Degree
-
Heating element:
-
MoSi2 Rod
-
Application:
-
Heat Treatment
-
Working temperature:
-
1600 Degree
-
Heating rate:
-
0-20℃/min
-
Power:
-
5KW
-
Work voltage:
-
220v 50HZ ,or custom-made
-
chamber size:
-
300*300*300mm
Quick Details
-
Warranty:
-
12 months
-
Brand Name:
-
JINMING
-
Model Number:
-
JM-1700M-27L
-
Place of Origin:
-
Henan, China
-
Product name:
-
1700 degree muffle furnace
-
Max temperature:
-
1700 Degree
-
Heating element:
-
MoSi2 Rod
-
Application:
-
Heat Treatment
-
Working temperature:
-
1600 Degree
-
Heating rate:
-
0-20℃/min
-
Power:
-
5KW
-
Work voltage:
-
220v 50HZ ,or custom-made
-
chamber size:
-
300*300*300mm
For gem sintering/pottery calcination 1700 degree laboratory sintering oven high temperature heat treatment furnace
Product Description :
This 1700 degree high temperature box furnace /muffle furnace adopts imported alumina polycrystalline fiber for furnace chambers , With good insulation performance, durable, high tensile strength, no stray ball, high purity, energy saving effect is obviously better than domestic fiber materials, and high temperature silicon molybdenum rod as heating element, the highest temperature can reach 1700℃; Double shell structure, advanced vacuum heat insulation technology, greatly reduce the box surface temperature; The B-type double platinum rhodium thermocouple is equipped with PID intelligent 30-stage temperature control system, and is equipped with over-temperature, decoupling, over-current protection and other functions. The furnace has the advantages of balanced temperature field, low surface temperature, fast rising and falling temperature rate, and energy saving.
| Technical parameter | ||
| Chamber size | 300*300*300mm ,capacity 27L (Accept custom-made size according to Clients demands) | |
| Max. temperature | 1700°C | |
| Working temperature | ≤1650℃ | |
| Temprature control |
|
|
| Heating rate | 0-20 o C /min | |
| Thermocouple | B type double platinum rhodium thermocouple | |
| Temperature accuracy | +/- 1 o C | |
| Heating element | High purity U type Model 1800 MoSi2 Heating element, less iron components, no pollution. | |
| Furnace structure | Double layer steel casing with dual cooling fan, temperature of furnace shell below 60 o C | |
| Thick Furnace Insulation |
Three layers of ceramic fiber insulation materials. 1) First layer: 1800 ° C ceramic fiber board 2 ) Second layer: 1600 ° C ceramic fiber board 3 )Third layer : 1260 ° C ceramic fiber board
|
|
Detailed Pictures :
Sintering result:
Packing & Delivery :
Our Products :
FAQ
1. Are you furnace manufacturer ?
A: Yes, we are professional lab furnace manufacturer with many years of sale and production experience in China.
2. Q:What kind terms of payment can be accepted?
A: D/P , T/T, Western Union, Paypal , etc.
3. Q: Could I ask for customized voltage and electricity plug ?
A: Yes,we can custom-made according to our clients demands from different countries .
4. Q: What about the delivery time?
A: Normally 15-20 days prouction time after received advance payment or based on order quantity and arrange production schedule.
5. Q: What about the guarantee period?
A: The furnace guarantee period is one year , and could supply technical support and service for free all the time .
6. Q: What is your advantages?
A: Professional and economical technical Proposal , Excellent quality and service ,and fast & reliable delivery .
