hay baler large square straw bale picking and bundling machine baler with crushing and dust removal function

hay baler large square straw bale picking and bundling machine baler with crushing and dust removal function

FOB Reference Price: Get Latest Price

≥1 Sets

US $25857.14

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Dimension(L*W*H):: 5100*2950*3930mm

Weight:: 4500 KG

Product name:: Square Hay Baler Machine

Advantage:: 3 times dust removal function

Picking Width:: 2200mm

Machine Size (Length*Weight*Height):: 5100*2950*3930mm

Walking Style:: Trailed

Bale Size:: 800*450*350mm (slightly expanded)

Work Efficiency:: 1.5-2.5t/h

Straw Bale Packaging Form:: Automatic Net Wrapping

Tractor Supporting Power:: ≥120HP

Soil Removal Rate:: ≥97%

Quick Details

Marketing Type:: Hot Product 2024

Place of Origin:: Liaoning, China

Application:: hay, wheat, rice straw

Dimension(L*W*H):: 5100*2950*3930mm

Weight:: 4500 KG

Product name:: Square Hay Baler Machine

Advantage:: 3 times dust removal function

Picking Width:: 2200mm

Machine Size (Length*Weight*Height):: 5100*2950*3930mm

Walking Style:: Trailed

Bale Size:: 800*450*350mm (slightly expanded)

Work Efficiency:: 1.5-2.5t/h

Straw Bale Packaging Form:: Automatic Net Wrapping

Tractor Supporting Power:: ≥120HP

Soil Removal Rate:: ≥97%

Product Description

9YFZ-2.2A Square Baler

Improve your agricultural productivity and make the 9YFZ-2.2A square bale picking and baling machine the core force of your farm operations.
Tractor-pulled walking mode : easy to connect and move freely. It greatly increases the flexibility and convenience of operations,can adapt to any terrain, and improves operation efficiency.
Super picking up ability: Its hammer claw has super picking up ability, picking up without missing anything, ensuring that every piece of forage is effectively collected, so that your land resources can be fully utilized.
Unique 2-time crushing and 3-time dust removal functions: the bales are cleaner and nutrients are not lost. The soil removal rate is as high as 97%, ensuring that the forage is clean and can be directly used to feed cattle and sheep.

Product Parameters

Product Number	9YFZ-2.2A
Product Type	Square Straw Bale Baling Machine
Picking Width	2200mm
Overall Machine Size (LengthWeightHeight)	5100×2950×3930mm
Walking Style	Trailed
Bale Size	800×450×350mm (slightly expanded)
Power Input Speed	720-760 rpm
Straw Bale Packaging Form	Automatic Net Wrapping
Warranty Period	1 Year
Tractor Supporting Power	≥120HP
Total Weight	4300kg
Work Efficiency	1.5-2.5t/h
Stubble Height	15-150mm
Length of Kneading Silk	The length of primary crushing is 15-6Cm, and the length of secondary crushing is 0.2-2Cm (the length can be adjusted according to the number of blades)
Soil Removal Rate	≥97%
Straw Bale Packaging Type	Plastic Bags, Nylon Woven Bags, Mesh Bags, Etc.

Product detail & advantages

The whole machine structure is reliable

The elastic anti-collision structure of the pick-up machine guide plate keeps the picking effect stable.
The split-detachable structure of the fan end plate makes it easy to quickly replace the housing wear-resistant plate and fan wear-resistant blades.
The wear-resistant block of the main piston is enlarged to extend the service life and reduce the number of replacements.
The automatic net-winding mechanism increases buffering and shock absorption and operates more smoothly.

Control system intelligence

1.The winding speed is adjustable, and high speed, medium speed and low speed can adapt to different operating needs.

2.Network-free monitoring function improves operation stability, prevents network-free packet loss, and provides timely reminders
when there is no network rope.

Hydraulic system is stable

The hydraulic system is fully optimized and upgraded to improve system stability and reduce operating fuel consumption.
The fuel tank is optimized, and double-layer baffles for the upper cover and air filter are added to facilitate maintenance, cleaning and maintenance.

Various optional devices

1.Fold the feeding bin and reduce the height of the whole machine to 3200mm (the height of the whole machine is reduced by 730mm).
2.The foldable bag guide device is easy to use, improves work efficiency, and provides better workability.

Product application

9YFZ-2.2 square baler can not only pick up the wheat straw scattered in the field after the combine harvester harvests, but also eliminate the wheat stubble left in the field after the combine harvester harvests.

For corn stalks, whether they are standing or lying down, they can be stubble-cutting, silk-shaping, and bundling.
For green corn stalks, green corn stalks can be covered with film after stubble-cutting, silk-shaping, and bundling to achieve the purpose of green shopping.
The corn straw stubble removal, rubbing, crushing and baling machine is an advanced straw collection and processing equipment. This machine relies on tractor traction and power transmission.
It can automatically complete the stubble removal, crushing and bundling of corn, rice, wheat, cotton and other straw and pasture. Bundle into one advanced ideal equipment.

About us

Advantages of modernized and automated production

Professional R&D team composed of industry elites

Quality is the basis for enterprise development

FAQ

Q1: What should you pay attention to when choosing a baler?
A1: Use the power supply and voltage, specifications and dimensions to ensure that the baler you receive can be used smoothly. If you are not sure which model specifications to choose, you can contact us for help.

Q2:What is your machine guarantee?
A2:Normally he guarantee period is 1 year, and we will keep contact with our customers for after-sales service. we're aim to produce better machines and let our customers be satisfied.

Q3:How can I get quotation?
A3:Send your requirements and leave your email, we will send you quotation soon.

Q4:If we have problems when using your machine, what should we do?
A4:If you have any problem, just contact us, we will help you to solve it, and if necessary , we will arrange our engineers to help you in your country.

Q5:What's your delivery time?
A5:Usually we produce within 7-15 days after the payment confirmed. It is also depend on the machines, if need to customize the machine as your requirement, the producing time is longer.
