Quick Details
-
Model Number:
-
TP03
-
Output Frequency:
-
50/60Hz
-
Product Name:
-
emergency driver led
-
High Efficiency:
-
88%
-
Surge protection:
-
1KV
-
Waterproof:
-
IP20
-
Star time:
-
<1S
-
P.F:
-
0.90
-
THD:
-
<20%
-
Size:
-
209*30*21MM
-
Warranty:
-
2 Years
Quick Details
-
Warranty(Year):
-
2-Year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
EMAI
-
Model Number:
-
TP03
-
Output Frequency:
-
50/60Hz
-
Product Name:
-
emergency driver led
-
High Efficiency:
-
88%
-
Surge protection:
-
1KV
-
Waterproof:
-
IP20
-
Star time:
-
<1S
-
P.F:
-
0.90
-
THD:
-
<20%
-
Size:
-
209*30*21MM
-
Warranty:
-
2 Years
SPECIFICATIONS
Specification
Input Voltage .............................................................................. (Universal) 200-240 VAC, 50/60Hz
Input Current (200V)
....................................................................................................
0.05A (max)
Output Voltage
...........................................................................................
20-75VDC/
70-200VDC
Output Current
.................................................................................................
Auto-Adjusting
Output Power
.................................................................................................
3/6/9 Watts (Constant)
Max. AC Driver Neutral Current
.......................................................................................
3Amps
Power Factor
.....................................................................................................................
<
0.5
Surge Protection
..........................................................
Line-Neutral 1KV,Line&Neutral-Ground 2KV
Emergency Operation
..........................................................................
180 minutes/
120mins
Operating Temp
.............................................................................................................
0° to 55° C
THD
..............................................................................................................
< 10% (@ full charge)
EMI
............................................................................................
Complies to FCC commercial limits
E
mergency Mode Protections
.....................................................
Battery Over VoltageProtection
Battery Under Voltage Protection
Battery Hot Plug at Normal Mode Protection
Battery Hot Plug at Emergency Mode Protection
Output Open P
rotection
Output Short
Protection
Battery
.......................................................................................
LiFePO4,6.4V 2Ah
Battery Charge Current
................................................................
300mA
Battery Recharge Time
................................................................
12Hours
