Quick Details
-
Application:
-
Balcony, Balcony,Swimming Pool,Staircase,etc.
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GOBO
-
Model Number:
-
GRP83
-
Product name:
-
Balustrades & Handrails
-
Hardware:
-
Post
-
Hardware Material:
-
Stainless Steel 304/316
-
Finished:
-
Polished/Brushed/Powder Coated Matte Black
-
Measurement:
-
950 mm/1067 mm/Customized
-
Glass:
-
Tempered Glass/Laminated Glass
-
Glass Thickness:
-
12 mm
-
Handrail Material:
-
Stainless Steel 304
-
Handrail Option:
-
Round: Dia 50 mm;Square: 40 mm*40 mm
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support, Railing
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Balcony, Balcony,Swimming Pool,Staircase,etc.
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GOBO
-
Model Number:
-
GRP83
-
Product name:
-
Balustrades & Handrails
-
Hardware:
-
Post
-
Hardware Material:
-
Stainless Steel 304/316
-
Finished:
-
Polished/Brushed/Powder Coated Matte Black
-
Measurement:
-
950 mm/1067 mm/Customized
-
Glass:
-
Tempered Glass/Laminated Glass
-
Glass Thickness:
-
12 mm
-
Handrail Material:
-
Stainless Steel 304
-
Handrail Option:
-
Round: Dia 50 mm;Square: 40 mm*40 mm
|
Product
|
Outdoor Post Stainless Steel 304/316 Railing Glass Balcony Balustrades & Handrails
|
|
|
|
|||
|
Name
|
Specification
|
Material
|
Finished/Surface
|
Noted
|
|||
|
Standoff/Pin
|
Dia38mm, 42mm, 50.8mm
|
304/316 Stainless Steel
|
Satin/Mirror/Powder Coated/Electroplated
|
Round Edge
|
|||
|
Glass
|
Thickness 12mm,Height 800mm-1500mm, often 1067mm outdoor.
|
Tempered/Toughened
|
Clear/ Ultra Clear
|
Round Edge
|
|||
|
Handrail
|
Round: Dia50mm, Square: 40mm*40mm
|
304 Stainless Steel
|
Satin/Mirror/Powder Coated/Electroplated
|
|
|||
|
U Channel
|
60mm*120mm
|
Aluminum Profile
|
Satin/ Nature/Matte Black
|
|
|||
|
Glass Spigot
|
Tall 160mm,180mm
|
304SUS/316SUS/2205
|
Satin/Mirror/Powder Coated/Electroplated
|
|
|||
|
Post
|
Customized Based on the height of glass railing. Often it is 950mm and 1067mm.
|
304SUS/316SUS
|
|
|
|||
|
Rod
|
Dia 6mm, Dia4mm,Dia8mm
|
|
Satin/ Nature
|
|
|||
|
Hardware Fittings
|
Bracket, Standoff, D clamp, Contact us for the details.
|
|
|
|
|||
GOBO's glass railings/balustrades are made of tempered glass. It is a kind of glass with high safety and strong strength. In order to increase the strength of glass, glass factories usually use chemical principles or physical methods to test the glass by applying pressure on the glass surface. When the glass bears the external force, it first offsets the surface stress, thereby improving the bearing capacity and enhancing the glass's resistance to wind pressure, cold and hot temperature changes, and impact forces.
Tips:
1
.
If the project is near the sea, the hardware material of the railing included the spigot, handrail, post is 316 stainless steel. The 316 stainless steel is
with strong anti-rust ability. The warranty is 5 years.
2
. The height of outdoor railing is 1067mm(42inches) and 955mm(37.6inches) indoor. They are the building core in Australia, Canada and USA.
If you have a specific measurement, let us know in advance, please.
3.
Before placing the order the CAD and 3D drawing are provided for confirming the measurement and the specification.
There are hot sale glass railing included the spigot railing, u channel railing and post railing. Contact us for the catalog. www.veryhardware.com. When you order the glass railing, the accessories are set up to you such as the standoff, D clamp, elbow and joint based on your chosen models.
GOBO Outdoor Post Stainless Steel 304/316 Railing Glass Balcony Balustrades & Handrails
