Quick Details
-
Output Speed:
-
75rpm
-
Place of Origin:
-
Sichuan, China
-
Product name:
-
Electric Speed Reducer
-
Application:
-
Machine Tool
-
Certificate:
-
CE Certificate
-
Warranty:
-
12 Months
-
Bearing:
-
NSK Bearing
-
Gear material:
-
40Cr
-
Mounting Position:
-
Flange
-
Efficiency:
-
90%
-
Lubrication:
-
Life Lubrication
-
Available Application:
-
Engineering
Quick Details
-
Gearing Arrangement:
-
Spur
-
Output Torque:
-
6N.m
-
Input Speed:
-
3000rpm
-
Output Speed:
-
75rpm
-
Place of Origin:
-
Sichuan, China
-
Product name:
-
Electric Speed Reducer
-
Application:
-
Machine Tool
-
Certificate:
-
CE Certificate
-
Warranty:
-
12 Months
-
Bearing:
-
NSK Bearing
-
Gear material:
-
40Cr
-
Mounting Position:
-
Flange
-
Efficiency:
-
90%
-
Lubrication:
-
Life Lubrication
-
Available Application:
-
Engineering
Performance Table (when input speed is 3000rpm)
Dimensional drawing
when frame size is 40mm, gear ratio is 3 4 5 8 10.
we can also provide other size and ratio gearbox, please contact us for more infomation
1)Series: PLE, PLF, PLS, WPL, WPLF, ZB, ZE, ZDF, ZDE, ZDS, ZDWF, ZDR, ZDG
2) Gearbox outline dimension: 40, 60, 80, 120, 160
3) Reduction ratio: 1~512
4) Lubrication: Lifetime lubrication
5) Input speed: 3000- 6000rpm
6) Life: 30, 000 hours
7) Backiash: Stage 1: <3 (arcmin)
Stage 2: <6 (arcmin)
Stage 3: <8 (arcmin)
8) Operating temperature: -25C to +90C
