Quick Details
-
Voltage:
-
220V/customized
-
Dimension(L*W*H):
-
N/M
-
Weight:
-
N/M
-
Air capacity:
-
N/M
-
Product name:
-
air compressor
-
Function:
-
supply compressed air
-
Color:
-
army green
-
MOQ:
-
1 set
-
Package type:
-
plywood box
-
Certificate:
-
CE & ISO
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TFAUTENF
-
Model Number:
-
TF-360/8-110L
-
Voltage:
-
220V/customized
-
Dimension(L*W*H):
-
N/M
-
Weight:
-
N/M
-
Air capacity:
-
N/M
-
Product name:
-
air compressor
-
Function:
-
supply compressed air
-
Color:
-
army green
-
MOQ:
-
1 set
-
Package type:
-
plywood box
-
Certificate:
-
CE & ISO
Product Description
We have various models for you to choose from
Model name: TF-250/8-70L
|
Power
|
2.2KW/3HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ65*2
|
|
Speed
|
900 rpm
|
|
Discharge pressure
|
8 bar
|
|
Air displacement
|
250 L/min
|
|
Air tank capacity
|
70 L
|
|
Gross weight
|
110 kgs
|
|
Package size
|
1050*420*800 mm (0.353CBM)
|
Model name: TF-360/8-110L
|
Power
|
3KW/4HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ65*3
|
|
Speed
|
920 rpm
|
|
Discharge pressure
|
8 bar
|
|
Air displacement
|
360 L/min
|
|
Air tank capacity
|
110 L
|
|
Gross weight
|
110 kgs
|
|
Package size
|
1190*450*940 mm (0.5CBM)
|
Model name: TF-360/12.5-110L
|
Power
|
3KW/4HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ65*2+φ51*1
|
|
Speed
|
920 rpm
|
|
Discharge pressure
|
12.5 bar
|
|
Air displacement
|
360 L/min
|
|
Air tank capacity
|
110 L
|
|
Gross weight
|
120 kgs
|
|
Package size
|
1230*380*900 mm (0.42CBM)
|
Model name: TF-600/8-120L
|
Power
|
4KW/5.5HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ90*2
|
|
Speed
|
900 rpm
|
|
Discharge pressure
|
8 bar
|
|
Air displacement
|
600 L/min
|
|
Air tank capacity
|
120 L
|
|
Gross weight
|
140 kgs
|
|
Package size
|
1200*480*880mm(0.51CBM)
|
Model name: TF-900/8-180L
|
Power
|
7.5KW/10HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ90*3
|
|
Speed
|
920 rpm
|
|
Discharge pressure
|
8 bar
|
|
Air displacement
|
900 L/min
|
|
Air tank capacity
|
180 L
|
|
Gross weight
|
190 kgs
|
|
Package size
|
1330*540*980mm (0.7CBM)
|
Model name: TF-900/12.5-180L
|
Power
|
7.5KW/10HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ90*2+φ65*1
|
|
Speed
|
920 rpm
|
|
Discharge pressure
|
12.5 bar
|
|
Air displacement
|
900 L/min
|
|
Air tank capacity
|
180 L
|
|
Gross weight
|
190 kgs
|
|
Package size
|
1330*540*980mm (0.7CBM)
|
Model name: TF-900/16-180L
|
Power
|
7.5KW/10HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ90*2+φ65*1
|
|
Speed
|
920 rpm
|
|
Discharge pressure
|
16 bar
|
|
Air displacement
|
900 L/min
|
|
Air tank capacity
|
180 L
|
|
Gross weight
|
190 kgs
|
|
Package size
|
1330*540*980mm (0.7CBM)
|
Model name: TF-1000/8-230L
|
Power
|
7.5KW/10HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ90*3
|
|
Speed
|
900 rpm
|
|
Discharge pressure
|
8 bar
|
|
Air displacement
|
1000 L/min
|
|
Air tank capacity
|
230 L
|
|
Gross weight
|
240 kgs
|
|
Package size
|
1600*540*1100mm (0.95CBM)
|
Model name: TF-1050/12.5-300L
|
Power
|
7.5KW/10HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ105*2 + φ55*2
|
|
Speed
|
680 rpm
|
|
Discharge pressure
|
12.5 bar
|
|
Air displacement
|
1050 L/min
|
|
Air tank capacity
|
300 L
|
|
Gross weight
|
360 kgs
|
|
Package size
|
1600*580*1200mm (1.11CBM)
|
Model name: TF-1050/16-300L
|
Power
|
7.5KW/10HP
|
|
Voltage
|
220V/380V/customized
|
|
Cylinder bore*QTY
|
φ105*2 + φ55*2
|
|
Speed
|
680 rpm
|
|
Discharge pressure
|
16 bar
|
|
Air displacement
|
1050 L/min
|
|
Air tank capacity
|
300 L
|
|
Gross weight
|
380 kgs
|
|
Package size
|
1600*580*1200mm (1.11CBM)
|
FAQ
1. What color do you have for these air compressor?
Army green, or black, we don't customize color if order quantity is small.
Army green, or black, we don't customize color if order quantity is small.
2. What kind of packages?
Plywood box with f ork mouth, seaworthy packages
Plywood box with f ork mouth, seaworthy packages
3. how can you guarantee quality?
Always s trictly control the production process
Always inspection and test before shipment
Always s trictly control the production process
Always inspection and test before shipment
4. What is the warranty?
12 months warranty, lifetime technical support
5. How to ship these air compressor?
Generally by sea
12 months warranty, lifetime technical support
5. How to ship these air compressor?
Generally by sea
