Quick Details
-
Application:
-
IPTV Live Streaming system
-
Input:
-
16 HD MI
-
Output:
-
IP Output 16 channels stream
-
Video encoding:
-
MPEG4 AVC/H.264
-
Audio encoding:
-
MPEG1 Layer 2 , MPEG4 AAC
-
Protocol:
-
HLS/HTTP/RTSP/RTMP/UDP/ONVIF2.4
-
Support:
-
Windows,Linux
-
WINDOWS Supports:
-
WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN764
-
LINUX Support:
-
multiple devices display at the same time with one computer
-
Management:
-
Web-based management
Quick Details
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
CatCast
-
Model Number:
-
HPK816D
-
Application:
-
IPTV Live Streaming system
-
Input:
-
16 HD MI
-
Output:
-
IP Output 16 channels stream
-
Video encoding:
-
MPEG4 AVC/H.264
-
Audio encoding:
-
MPEG1 Layer 2 , MPEG4 AAC
-
Protocol:
-
HLS/HTTP/RTSP/RTMP/UDP/ONVIF2.4
-
Support:
-
Windows,Linux
-
WINDOWS Supports:
-
WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN764
-
LINUX Support:
-
multiple devices display at the same time with one computer
-
Management:
-
Web-based management
16 Channels HD MI H.264 OTT IPTV Encoder support IPTV Wowza Server FMS Server
Product Description
Summary
HPK816D 16 Channel MPEG-4/AVC H.264 HD Encoder is a professional audio&video encoding device, which realize Video & Audio real-time transmission via internet, it support 16 channels HD MI input and 16 channels IP stream data output, adopt the advanced MPEG-4 AVC/H.264 video encoding technology, and it is highly compatible with IPTV server like Wowza server, FMS server etc.Moreover,with powerful video pre-compression and efficient adaptive video compression algorithm, it is able to provide clear-delicate, high quality video even at lower bit rate compare than traditional broadcast Encoder. It can be widely applied to education, health care, IPTV, live broadcast,Hotel TV system, conference, remote education, news interview,court, public security, banking, transportation and other industry application.It provides the complete second development kits to system developers,through the SDK, system developers can take system design by
VB,VC programming software.
VB,VC programming software.
Key Features
●
Support 16xHD MI channels input (support HDCP), 1U or 3U racked optional
●
Supports resolution: 1920x1080/ 1280x720 /1280x1024 /1280x960 /704x576/720x576/720x480 /640x480 /352x288 /320x480,Automatic scaling
●
MPEG-4 AVC/H264 High&Main Profile video encoding MP3&AAC audio encoding
●
Output 16 channels IP stream data, Support RTSP/RTP, HLS/HTTP, RTMP,UDP protocol Highly compatible with IPTV server like Wowza server, FMS server etc.
●
Supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN764, LINUX Support multiple devices display at the same time with one computer .
●
Rate control: CBR/VBR 16KBIT/S~40MBIT/S
●
Web-based management
Specification
|
Video
|
Input
|
16x HD MI , support HDCP
|
|
|
||
|
|
Resolution
|
1920x1080 / 1280x720 / 1280x1024 / 1280x960 / 704x576 /
720x576/ 720x480 /640x480 /352x288 /320x480 |
|
|
||
|
|
Encoding
|
H.264/AVC High&Main Profile Level 4.0
|
|
|
||
|
|
Data Rate
|
0.8Mbps~12Mbps
|
|
|
||
|
|
Rate Control
|
CBR/VBR
|
|
|
||
|
|
GOP Structure
|
IBBP
|
|
|
||
|
|
Advanced Pretreatment
|
De-interlacing, Noise Reduction, Sharpening
|
|
|
||
|
Audio
|
Encoding
|
MPEG-1 Layer 3 (MP3), MPEG-4 AAC
|
|
|
||
|
|
Sampling rate
|
Auto
|
|
|
||
|
|
Bit-rate
|
32K/48K/64K/96K/128K/160K/192K
|
|
|
||
|
|
Sampling precision
|
24 bit
|
|
|
||
|
|
Data Rate
|
64Kb/s~384Kb/s
|
|
|
||
|
System
|
RJ45 port
|
100/1000M Base-T Ethernet interface
|
|
|
||
|
|
Protocol
|
HLS/HTTP/ UDP/ RTMP/ RTSP/ RTP/ONVIF
|
|
|
||
|
|
Control interface
|
WEB-GUI interface
|
|
|
||
|
|
Upgrade
|
Software can be upgraded via network
|
|
|
||
|
General
|
Dimension (W× L× H)
|
430mm x 330mm x145mm (3U rack)
482mm x 410mm x 45mm (1U rack)
|
|
|
||
|
|
Weight
|
8 kg
|
|
|
||
|
|
Temperature
|
0~45°C(operation),-20~80°C(storage)
|
|
|
||
|
|
Double Power
|
110-220V AC
|
|
|
||
|
|
Consumption
|
90W
|
|
|
||
Market Coverage
1.IPTV
2.Digital Signage
3.Video Conference
4.Replace HD Video Capture Card
5.Hotel TV system
6.Live Broadcast
7.Teaching/Campus Broadcast
8.Recording System
9.NVR(Net Video Recorder)
10.Support WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32/WIN7 64, LINUX
Related Products
Packing&Shipping
Package type: each pcs wth soft ,safety polyfoam ,then packed in brown box
Shipping way: it usually take 5-7 days by DHL, TNT, Fedex, UPS to arrive your local place
