- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HBAN
-
Model Number:
-
HBGQ12F-10/J/N
-
IP level:
-
IP65
-
Product name:
-
12mm 1NO flat head Push Button waterproof metal switch
-
Material:
-
Nicel-plated Brass
-
Mounting Hole Size:
-
12mm
-
Shape:
-
Flat Head
-
Operation type:
-
Momentary
-
Terminal type:
-
Pin Terminal/Screw Terminal
-
Contact Confiquration:
-
1NO
-
Protection degree:
-
IP65,IK08
-
Certificate:
-
CE RoHS,ISO9001
Quick Details
-
Protection Level:
-
IP65,IK08
-
Max. Current:
-
2A
-
Max. Voltage:
-
36VDC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HBAN
-
Model Number:
-
HBGQ12F-10/J/N
-
IP level:
-
IP65
-
Product name:
-
12mm 1NO flat head Push Button waterproof metal switch
-
Material:
-
Nicel-plated Brass
-
Mounting Hole Size:
-
12mm
-
Shape:
-
Flat Head
-
Operation type:
-
Momentary
-
Terminal type:
-
Pin Terminal/Screw Terminal
-
Contact Confiquration:
-
1NO
-
Protection degree:
-
IP65,IK08
-
Certificate:
-
CE RoHS,ISO9001
Product Paramenters
|
Metal Push Button Switch Without Led
|
|
|
|
Mounting hole size:
|
12mm
|
|
|
Switch value:
|
2A/36V DC
|
|
|
Operation type:
|
Momentary
|
|
|
Contact configuration:
|
1NO,1NC
|
|
|
Head shape:
|
High
|
|
|
Crust material:
|
Stainless Steel, Nickel-plated brass
|
|
|
Terminal type:
|
Pin terminal
|
|
|
Electrical life :
|
≥50,000 times
|
|
|
Mechanical life:
|
≥1，000,000 times
|
|
|
Operation temperature:
|
-40℃~+80℃
|
|
|
Contact Resistance:
|
≤50mΩ
|
|
|
Insulation Resistance:
|
≥1000mΩ
|
|
|
Protection grade :
|
IP65
|
|
|
Contact material:
|
Silver alloy
|
|
Products Description
Company information
Product packaging
We pack 50 pieces diameter 12mm metal push button switch into 1 foam box to protect them .We supply 50 pieces rubber rings.Then we packed this foam box into a plastic bag,it will packed into a small box with 3 layers corrugated Finally ,we packed 20 boxes / 25 boxes into a 5 layers corrugated export carton.
FAQ
Q:Do you have a catalog? Can you send me the catalog to me for checking them ?
A: Yes , We have product catalog.Please contact us on line or send an Email to hb at hban.cc for send-ing the catalog.
A: Yes , We have product catalog.Please contact us on line or send an Email to hb at hban.cc for send-ing the catalog.
Q: Can you provide samples ?
"A: Yes,we can provide samples.
we will collect samples fee(1-3pcs)and you have to pay for the shipping cost.when you place normal order.we will refund the samplefee for you."
"A: Yes,we can provide samples.
we will collect samples fee(1-3pcs)and you have to pay for the shipping cost.when you place normal order.we will refund the samplefee for you."
Q: What kind of payment do you accept ?
"A: We accept T/T(Wire transfer),Western Union and Paypal,credit card. Please be sure that we can re-ceive the same amount of the Invoice.
"A: We accept T/T(Wire transfer),Western Union and Paypal,credit card. Please be sure that we can re-ceive the same amount of the Invoice.
Q : What about your delivery time?
"A: We have a lot of products in stock.We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you.will update to you within 48 hours"
"A: We have a lot of products in stock.We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you.will update to you within 48 hours"
Q : How to ship my order ? Is it safe?
A: For small package, we will send it by Express, such as DHL,FedEx,UPS,TNT.That’s a Door to Door service.
For big packages, we will send them by Air or By sea.We will use good packing and ensure the safet-y.We will be responsible to any product damage caused on delivery.
A: For small package, we will send it by Express, such as DHL,FedEx,UPS,TNT.That’s a Door to Door service.
For big packages, we will send them by Air or By sea.We will use good packing and ensure the safet-y.We will be responsible to any product damage caused on delivery.
