Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sunricher
-
Product name:
-
Zigbee 3.0 Triac Dimmer Switch 400W driver
-
Certificates:
-
ZIGBEE Ceritifed
-
Size:
-
45.5x45x20.3mm
-
Operation Frequency:
-
2.4G
-
Control Color:
-
single color
-
Push:
-
push dim compatible
-
Voltage:
-
100-240VAC
Quick Details
-
Warranty(Year):
-
5-Year
-
Type:
-
MANUAL SWITCH
-
Max. Load Power:
-
400W
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sunricher
-
Product name:
-
Zigbee 3.0 Triac Dimmer Switch 400W driver
-
Certificates:
-
ZIGBEE Ceritifed
-
Size:
-
45.5x45x20.3mm
-
Operation Frequency:
-
2.4G
-
Control Color:
-
single color
-
Push:
-
push dim compatible
-
Voltage:
-
100-240VAC
AC Phase Cut ZigBee Dimmer Zigbee 3.0 Triac Dimmer Switch 400W driver
Zigbee phase cut dimmer to let your existing lighting voice control or wifi control
ZigBee AC phase cut dimmer based on latest ZigBee 3.0 protocol
• 100-240VAC Wide Input and Output Voltage
• Supports resistive loads and capacitive loads
• 1 Channel Output, Up to 400W
• Input and Output with Screw Terminals, Safe and Reliable
• Both leading edge version and trailing edge version are available for choosing
• Enables to control ON/OFF and light intensity of connected triac dimmable led light or led driver
• ZigBee end device that supports Touchlink commissioning
• Can directly pair to a compatible ZigBee remote via Touchlink without coordinator
• Supports self-forming zigbee network without coordinator and add other devices to the network
• Supports find and bind mode to bind a ZigBee remote
• Supports zigbee green power and can bind max. 20 zigbee green power remotes
• Compatible with universal ZigBee gateway products
• Can be controlled by universal 8-230V input single wire push switch
• Mini Size, Easy to be Installed into a standard 86*86mm wall box
• Radio Frequency : 2.4GHz
Reset • Waterproof grade: IP20
