Quick Details
-
Brand Name:
-
Chuanbai
-
Model Number:
-
LDS-5
-
Max Load:
-
5000N
-
Function:
-
Tensile Test
-
Power Supply:
-
AC 220V 50HZ
-
Standard:
-
ASTM ISO EN Can Customized Follow Yours
-
Delivery Time:
-
5-7 Working Days
-
Tensile Space:
-
700MM
-
Application:
-
Textile, Rubber, Non-woven, Plastic
Quick Details
-
Warranty:
-
1 year, 12 Months
-
Power:
-
400W
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Chuanbai
-
Model Number:
-
LDS-5
-
Max Load:
-
5000N
-
Function:
-
Tensile Test
-
Power Supply:
-
AC 220V 50HZ
-
Standard:
-
ASTM ISO EN Can Customized Follow Yours
-
Delivery Time:
-
5-7 Working Days
-
Tensile Space:
-
700MM
-
Application:
-
Textile, Rubber, Non-woven, Plastic
|
Max Load
|
5000N(optional force value)
|
|
Accuracy
|
Grade 1
|
|
Test Force Error Limit
|
Within ±1% of the indicated value
|
|
Load Measurement Range:
|
2% to 100% FS of full scale
|
|
Displacement Indication Limit Error:
|
Within ±1% of the indicated value
|
|
Displacement Resolution:
|
0.01mm
|
|
Displacement Speed Adjustment Range:
|
0.01-500mm/min
|
|
Displacement Rate Control Accuracy:
|
When the speed is ≥1mm/min, within ±0.5% of the set value
|
|
Effective Stretching Space Distance:
|
0-800mm
|
|
Host Size (L*W*H)
|
420*280*1580(mm)
|
|
Power Supply
|
220v, 50hz
|
|
power
|
0.4kw
|
Display function
Stretching fixture
The printer displays:
Machine housing
1. Are you a manufacturer?
Yes, we are the largest manufacturer of universal tensile testing machines and have a history of more than 11 years.
2. Do you have after-sales service?
In general, every machine shipped from our factory provides 12 months of free maintenance. If your machine does not work properly, you can contact us and we will try our best to communicate with you via email or skype video chat. We promise we will reply to you within 24 hours and with 3 Within a working day to provide solutions.
3. What is the delivery deadline?
Most of the time, we have inventory at the factory. If not, the delivery time is usually 15 to 20 days after receiving the payment. If you need it urgently, we can consider making special arrangements for you.
4. What kind of packaging and transportation do you use?
Under normal circumstances, we will use ordinary orders such as DHL, Fedex, UPS TNT transport. Large orders will use aviation or shipping.
5. Can the device be customized?
We can not only provide standard machines, but we can also provide customized machines according to your needs.At the same time, we can also place your trademark on the machine.
6. What kind of packaging do you use?
Plastic sealed and sturdy wooden box.
7. What payment methods do you support?
Paypal, T/T, Western Union and Escow.
