Automatic HDPE Pipe Butt Welding Machine for Water Pipe Repair Construction

Automatic HDPE Pipe Butt Welding Machine for Water Pipe Repair Construction

FOB Reference Price: Get Latest Price

≥1 Sets

US $5460

≥10 Sets

US $4430

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Frequency:: Alternative

Welding Area:: Adjustable

Dimensions:: Cutomized

Use:: PE pipe welding

Weight (KG):: 20 KG

Power (kW):: 4

Product name:: HDPE Pipe Butt Welding Machine for Water Pipe Repair Construction

Application:: Water Pipe Repair Construction

Function:: PVC Wedling Machine

Color:: Customer's Requirement

Material:: Stainless Steel

Certificate:: CE ISO

Welding material:: HDPE PE PVC

Package:: Wooden Case

Welding Time:: 0-10S Adjustable

Quick Details

Place of Origin:: Jiangsu, China

Brand Name:: WINCOO

Voltage:: 380V,220V

Frequency:: Alternative

Welding Area:: Adjustable

Dimensions:: Cutomized

Use:: PE pipe welding

Weight (KG):: 20 KG

Power (kW):: 4

Product name:: HDPE Pipe Butt Welding Machine for Water Pipe Repair Construction

Application:: Water Pipe Repair Construction

Function:: PVC Wedling Machine

Color:: Customer's Requirement

Material:: Stainless Steel

Certificate:: CE ISO

Welding material:: HDPE PE PVC

Package:: Wooden Case

Welding Time:: 0-10S Adjustable

Product Description

Suitable for butt welding of plastic pipes and fittings made of PE, PP and PVDF in a ditch in worksite or workshop.Consists of basic frame, hydraulic unit, planing tool, separate heating plate, support for planing tool & heating plate, and optional parts.

Suitable for PE,HDPE,PP pipe with OD 160mm 180mm 200mm 225mm 280mm to OD 315mm butt-fusion welding
Clamping device and control system is separate which is easy to operate.
It consists of hydraulic or electric clamping device, heating panel and milling cutter.
The clamping device is with chuck structure, pipe positioning is good,and easy to adjust the gap.
Utilize hydraulic system to control fitting-up.
Temperature control and hydraulic control system are integrated in interface.
Utilize electric temperature control on Heating device , digital display clear and accurate
Utilize magnetic value to reach cylinder electric control.
Electronic milling cutting system with limit switch to avoid accident

Size Information

Pipe range	Dn90-315
Temperature control	0-300ºC/220V
Temperature deviation	±5ºC
Heating device power	1.5KW/220V
Milling cutter power	1.0KW/220V
Hydraulic pump power	0.75 KW
Power source	220V, 60Hz
Pressure adjustment ranges	0~6.3Mpa
Supply scope	One set Hydraulic pump station, clamping device one set;milling cutter one set.

Major Component

Main Body

The main body supports and centres the plastic pipes with two fixed and two movable clamps.

Using the hydraulic pressure on the system, the two pistons on the carrying metal bars move the clamps forward and backward and supply the necessary movement for the welding process.

Milling Cutter

The milling cutter is the tool which clean and smooth the both ends of the pipes before the heating process .

HDC160 butt welding machine is designed for self aligning facer always produces parallel pipe faces.

Heater

The pipe ends will be heated by this heater before the welding process. The setting of the heater will be done by the thermostat on the plates. HDC160 butt welding machine PTFE-coated heating element and uniform surface temperature.

Hydraulic Unit

The necessary electric will be transported to the heater and milling cutter by means of this unit and to the main machine by the hydraulic pressure.

Support

The protective casing prevents heat loss of the heater and protects the trimmer from external effects.

Our Advantages

1, Removable PTFE coated heating plate with high accurate temperature control system.
2, Electric planning tool with safety limit switch enables to start it only when it is locked in operation position.
3, Made of lightweight and high strength material.
4, Low starting pressure and high reliable seal structure.
5, Changeable welding position brings more convenience while welding various fittings.
6, Separate two-channel timer records times in soaking and cooling phases.
7, High-accurate and shockproof pressure meter indicates clearer readings.
8, Labor saving and high efficient crane is available to lift planing tool and heating plate .

Detailed Images
