Quick Details
-
Horsepower:
-
251 - 350hp
-
Cargo Tank Type:
-
Van
-
Gross Vehicle Weight:
-
25000
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service
-
Brand Name:
-
Shacman
-
Place of Origin:
-
Shaanxi, China
-
Size:
-
9775x2490x3210mm
-
Cargo Tank Dimension:
-
standard
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Express transportation
-
Horsepower:
-
251 - 350hp
-
Cargo Tank Type:
-
Van
-
Gross Vehicle Weight:
-
25000
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service
-
Brand Name:
-
Shacman
-
Place of Origin:
-
Shaanxi, China
-
Size:
-
9775x2490x3210mm
-
Cargo Tank Dimension:
-
standard
|
Model |
SX1254JM434 |
|
Drive type |
6×4 |
|
Weight |
|
|
Complete kerb mass (kg) |
11000 |
|
GVW (kg) |
32500 |
|
Dimensions |
|
|
Max.length(mm) |
9775 |
|
Max.width(mm) |
2490 |
|
Max.heigh(mm) |
3210 |
|
Front / Rear overhang(mm) |
1525/2575 |
|
Wheel base(mm) |
4325+1350 |
|
Track width(mm) |
2036/1800 |
|
Engine |
|
|
Brand |
WEI CHAI |
|
Model |
WD615.50 |
|
Power(kw/HP) |
206/280 |
|
Max.Torque (N.m )/rpm |
1160/1100—1600 |
|
Displacement (L) |
9.726 |
|
Emmission Standards |
Euro Ⅱ |
|
Transmission |
|
|
Brand |
FAST |
|
Model |
9JS119 |
|
Control type |
manual |
|
Gear Shift |
9-forward and 1 reverse speeds |
|
Brakes |
|
|
Type |
Drum |
|
Service brake |
With dual-circuit
|
|
Park brake |
Power spring brake acting
|
|
Auxiliary brake |
WEVB |
|
Option |
ABS |
|
Steering |
|
|
Type |
Integral circulating ball
|
|
Option |
Power steering |
|
Chassis |
|
|
Type |
Ladder structure with
|
|
Dimensions (mm) |
300×80×(8+7) |
|
Suspension |
|
|
Front Suspension |
Longitudinal leaf spring |
|
Rear Suspension |
Inverted leaf spring stabilizator suspension |
|
Axles |
|
|
Brand |
HANDE |
|
Front axle |
7500kg |
|
Rear axle |
13000kg(each other)
|
|
Ratio |
4.8 |
|
Tyres |
|
|
Type (Standard) |
12.00-20 |
|
Option |
12.00R20/11.00-20/11.00R20/12R22.5 |
|
Fueltank |
|
|
Tank capacity (L) |
380 |
|
Material |
Metal |
|
Cab |
|
|
Type |
MAN F2000, Lengthened flat roof |
|
Other |
|
|
Platform dimentions(mm) |
7000×2326×800 |
