Quick Details
-
Brand Name:
-
None
-
Supplier Type:
-
OEM/ODM
-
Frequency Range:
-
136~174MHz, 220~240MHz, 410~470MHz
-
Interface Type:
-
RS232&RS485 or TTL&RS485
-
Software Program:
-
Yes
-
Air data rate:
-
1200bps-115200bps settable by user
-
Baud rate:
-
1200bps-115200bps settable by user
-
Transmit Power:
-
5W/8W
-
Transmission Distance:
-
8-10km(Line of sight)
Quick Details
-
Application:
-
industrial
-
Model Number:
-
XZ-DT25-M
-
Place of Origin:
-
Shenzhen,China
-
Brand Name:
-
None
-
Supplier Type:
-
OEM/ODM
-
Frequency Range:
-
136~174MHz, 220~240MHz, 410~470MHz
-
Interface Type:
-
RS232&RS485 or TTL&RS485
-
Software Program:
-
Yes
-
Air data rate:
-
1200bps-115200bps settable by user
-
Baud rate:
-
1200bps-115200bps settable by user
-
Transmit Power:
-
5W/8W
-
Transmission Distance:
-
8-10km(Line of sight)
Product Description
Product Features
♦
Support frequency VHF(136MHZ-174MHZ,220-240MHZ)UHF(410MHZ-470MHZ) user program;
♦ RS232&RS485 2 interface default,TTL can be set in factory;
♦ High receiving sensitivity up to -123dBm;
♦ Over-the-air data rate from 1200bps to 115200bps and baud rate 1200-115200bps user programming;
♦ Short transmitting-receiving transfer time; communication delay less than 3Ms.
♦ RS232&RS485 2 interface default,TTL can be set in factory;
♦ High receiving sensitivity up to -123dBm;
♦ Over-the-air data rate from 1200bps to 115200bps and baud rate 1200-115200bps user programming;
♦ Short transmitting-receiving transfer time; communication delay less than 3Ms.
Technical Parameters
|
Frequency Range
|
136～174MHz, 220～240MHz, 410～470MHz
|
|
Frequency stability
|
≤±2.5PPm
|
|
Transmit Power
|
5W,8W
|
|
Modulation
|
GFSK
|
|
Air Data Rate
|
1200～115200bps settable by user
|
|
Baud Rate
|
1200～115200bps settable by user
|
|
Interface
|
RS232 and RS485 default, TTL customized
|
|
Power Supply
|
12V@10A
|
|
Interface Data Format
|
8E1/8N1/801
|
|
Receiving Sensitivity
|
-123dBm@1200bps/-120dBm@9600bps
|
|
Channel Bandwidth
|
10KHZ@1200bps/25KHZ@9600bps
|
|
Emission Current
|
≤2A (Recommend max.output current of power supply no less than 3A）
|
|
Receiving Current
|
≤80mA
|
|
Working Temperature&humidity
|
-40℃～80℃ (industrial grade),10% to 90% relative humidity, no condensation
|
|
Dimension(L/W/H)
|
105X 88X 62mm
|
|
Weight(g)
|
≤500g
|
Pin Definitions
Software Program
Applications
Industrial telemetry & wireless remote control or Paging system
Gas and oil flow monitoring
Electricity, water and gas utilities
Earthquake, weather, environmental protection
Vehicle tracking and asset tracking systems
Water monitoring, waste water management and irrigation control
Railway, police, army automation system
Aerial defense and fire alarm system
Urban lighting control
Gas and oil flow monitoring
Electricity, water and gas utilities
Earthquake, weather, environmental protection
Vehicle tracking and asset tracking systems
Water monitoring, waste water management and irrigation control
Railway, police, army automation system
Aerial defense and fire alarm system
Urban lighting control
