Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
HCX
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1800*1500*1450mm
-
Weight:
-
1500 kg
-
Marketing Type:
-
Hot Product
-
Technical feature:
-
Accurate slitting,fast speed,high efficiency and smooth cutting edge
-
Paper feeding:
-
Automatic paper feeding
-
Tension control system:
-
Automatic tension controller
-
Meter mode:
-
Automatic metering,pneumatic conveying waste discharge
-
Count way:
-
Automatic coding
-
Control system:
-
Adjustable tension of the paper-roll
-
Tightness of paper roll:
-
180m/min
-
Paper receiving mode:
-
Paper reeling functions with no spindle
-
Paper flattening method:
-
Equipped with bowed roll,No paper jam
-
Advantage:
-
One button controlling
Quick Details
-
Type:
-
Slitting Rewinder
-
Production Capacity:
-
180 m/min
-
Max. workable width:
-
1200mm
-
Place of Origin:
-
China
-
Brand Name:
-
HCX
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1800*1500*1450mm
-
Weight:
-
1500 kg
-
Marketing Type:
-
Hot Product
-
Technical feature:
-
Accurate slitting,fast speed,high efficiency and smooth cutting edge
-
Paper feeding:
-
Automatic paper feeding
-
Tension control system:
-
Automatic tension controller
-
Meter mode:
-
Automatic metering,pneumatic conveying waste discharge
-
Count way:
-
Automatic coding
-
Control system:
-
Adjustable tension of the paper-roll
-
Tightness of paper roll:
-
180m/min
-
Paper receiving mode:
-
Paper reeling functions with no spindle
-
Paper flattening method:
-
Equipped with bowed roll,No paper jam
-
Advantage:
-
One button controlling
Product Description
| Model | HX-650WG | HX-900WG |
| Width of paper-roll | 650mm | 900mm |
| Max. unreeling diameter | 1200mm | 1200mm |
| Max. reeling diameter | <=260mm | <=260mm |
| Spindle diameter | >=8mm | >=8mm |
| Sliting width | >20mm | >20mm |
| Production speed | 180m/min | 180m/min |
| Reeling spindle | 8-50mm | 8-50mm |
| Power | 3HP/380V/50Hz/2.2KW | 3 HP /380V/50Hz/2,2KW |
| Size(L*W*G) | 1800*1450*1450mm | 1800*1500*1450mm |
| Weight | 1250Kg | 1500kg |
