Quick Details
-
Brand Name:
-
HUAYI
-
Product name:
-
housing
-
Function:
-
Water Treatment Systerm
-
Usage:
-
Water Treament
-
Capacity:
-
19 core
-
Feature:
-
customized
-
Certification:
-
ISO9001
-
After Warranty Service:
-
Video Technical Support\Online Support\Spare Parts
Quick Details
-
Material:
-
Silicon Carbide
-
Place of Origin:
-
CHNA
-
Model Number:
-
SIC MEMBRANE
-
Brand Name:
-
HUAYI
-
Product name:
-
housing
-
Function:
-
Water Treatment Systerm
-
Usage:
-
Water Treament
-
Capacity:
-
19 core
-
Feature:
-
customized
-
Certification:
-
ISO9001
-
After Warranty Service:
-
Video Technical Support\Online Support\Spare Parts
Product Description
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
|
Shandong
|
|
Type
|
Ceramic Tubes
|
|
Application
|
Industrial Ceramic
|
|
Material
|
Silicon Carbide
|
|
Model Number
|
HYM-001
|
|
Brand Name
|
HUAYI
|
|
Processing Service
|
Bending, Welding, Cutting, Punching, Decoiling, Moulding
|
|
Product name
|
SIC ceramic membrance, Silicon carbide ceramic filter element
|
|
Shape
|
porous tube
|
|
Raw material
|
99% silicon carbide
|
|
Feature
|
Acid and alkali resistance and High temperature resistance
|
|
Color
|
Gray
|
|
Working temperature
|
1-800 Degree
|
|
Resistant Chemical
|
PH0-14
|
|
Membrane Structure
|
Asymmetry
|
|
Length
|
1200mm
|
|
Tube outer diamater
|
40mm
|
|
Number of channels
|
37
|
|
Channel diameter
|
4mm
|
|
Pore diamater
|
100Nm
|
|
surface area
|
10.64㎡
|
|
Operating pressure
|
1-5 bar
|
|
Flux
|
3000L/㎡•h
|
|
Applicable Ph value
|
0-14
|
Product Description
Silicon carbide ceramic membrane is considered as one of the high-end membrane technologies in the world. It can reach 100 times that of traditional organic membrane materials and 3-5 times that of ordinary ceramic membranes.
Silicon carbide ceramic microfiltration and ultrafiltration membranes are sintered at a high temperature of 2300 °C. The surface of silicon carbide crystal particles is smooth and round, and the support layer and separation layer have no sealed pores and channels.
Advantages:
The membrane layer is not easy to fall off and can be returned to the furnace for regeneration, which greatly improves the life of the membrane body; it is more suitable for the backwashing process, so that the membrane holes are not easily blocked, and the service life is as long as fifteen years.
SEM for Sic membrane
Separation membrane layer
SEM for Sic membrane
support layer
SEM for Sic membrane
transition Layer
Why Choose Us
Packing & Delivery
Inner packing:Shockproof foam board.
Outer packing:Carton or Case.
