Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SL
-
Model Number:
-
42BLF20
-
Torque:
-
0.063Nm
-
Model:
-
42BLF20
-
Number of poles:
-
8
-
Volatge:
-
12/24/36V
-
No load Speed:
-
5300rpm
-
Rated Power:
-
25W
-
Rated torque:
-
0.063Nm
-
Peak torque:
-
0.18Nm
-
Rated current:
-
1.6A
-
Weight:
-
0.29kg
-
Length:
-
43mm
Quick Details
-
Speed(RPM):
-
0-6000RPM
-
Continuous Current(A):
-
1.6A
-
Efficiency:
-
IE 2
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SL
-
Model Number:
-
42BLF20
-
Torque:
-
0.063Nm
-
Model:
-
42BLF20
-
Number of poles:
-
8
-
Volatge:
-
12/24/36V
-
No load Speed:
-
5300rpm
-
Rated Power:
-
25W
-
Rated torque:
-
0.063Nm
-
Peak torque:
-
0.18Nm
-
Rated current:
-
1.6A
-
Weight:
-
0.29kg
-
Length:
-
43mm
Application
Product Attribute
| SL42BLF Brushless DC Motor | ||||||||
| Technical Specification | ||||||||
| Model | 42BLF20 | 42BLF40 | 42BLF60 | 42BLF80 | ||||
| Number of poles | 4 | |||||||
| Voltage | V | 12/24/36/48 | ||||||
| No load speed | RPM | 5300 | 5400 | 5200 | 5200 | |||
| Rated torque | N.m | 0.063 | 0.125 | 0.185 | 0.24 | |||
| Rated speed | 0-6000RPM | |||||||
| Rated power | W | 25 | 50 | 75 | 100 | |||
| Rated current | A | 1.6 | 3.2 | 4.7 | 6.5 | |||
| Peak torque | N.m | 0.18 | 0.37 | 0.54 | 0.72 | |||
| Back-EMF constant | V/KRPM | 3.3 | 3.23 | 3.38 | 3.36 | |||
| Weight | Kg | 0.29 | 0.47 | 0.65 | 0.87 | |||
| Length | mm | 43 | 63 | 93 | 113 | |||
