Quick Details
-
Model Number:
-
QSD
-
Protection Level:
-
IP67
-
Operating Temperature:
-
-20℃-+60℃
-
Max. Current:
-
8A
-
Certification:
-
CE
Quick Details
-
Max. Voltage:
-
4kv
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Leraun
-
Model Number:
-
QSD
-
Protection Level:
-
IP67
-
Operating Temperature:
-
-20℃-+60℃
-
Max. Current:
-
8A
-
Certification:
-
CE
Why Choose Us
Product Description
Specification
|
Brand Name
|
LERAUN
|
|
Model No.
|
QSD
|
|
Protection level
|
IP67(EN60947-5-01,Except for the key operation hole）
|
|
Durability
|
Machinical 1,000,000 operations min.Electrical 500,000 operations min
|
|
Rated insulation voltage
|
400V
|
|
Use Category
|
AC-15
|
|
Rated impulse withstand voltage
|
4KV
|
|
Supply voltage
|
12-24VDC
|
|
Rated open thermal current
|
8A
|
|
Forced Disengagement Distance
|
≥10mm
|
|
Ambient Humidity
|
Below 83%RH
|
