Quick Details
-
Brand Name:
-
BTMA
-
Weight:
-
1500 KG
-
Product name:
-
Jaw Crusher Machine
-
Keyword:
-
Fine Stone Jaw Crusher
-
Color:
-
Customer Requirement
Quick Details
-
Application:
-
mobile quarry crusher plant
-
Capacity(t/h):
-
1-5t/h
-
Place of Origin:
-
HEN
-
Brand Name:
-
BTMA
-
Weight:
-
1500 KG
-
Product name:
-
Jaw Crusher Machine
-
Keyword:
-
Fine Stone Jaw Crusher
-
Color:
-
Customer Requirement
Mobile Jaw Crusher With Vibrating Screen
Products Description
Jaw Crusher
is typically used as primary crushers, or the first step in the process of reducing rock. They typically crush using compression. The rock salt lump is dropped between two rigid pieces of metal, one of which then move inwards towards the rock,and the rock salt lump is crushed because it has a lower breaking point than the opposing metal piece. Jaw crusher movement is obtained by using a pivot point located at one end of the "swing jaw", and an eccentric motion located at the opposite end.
BTMA stone crusher machine, a type of jaw crusher is widely used in mining, railway construction, water conservancy project,metallurgy, chemical, building material industries. It is mainly used to crush rock and ore, whose compression strength is less than 320 Mpa. Jaw crusher, your preferred primary crusher, is used for coarse crushing and fine crushing.
Through the screening function of the small vibrating screen, the crushed materials can be classified according to different particle size requirements to meet different production needs. At the same time, the small vibrating screen can also effectively remove impurities and foreign matter in the material. The large material will stay on the screen, while the small material will pass through the screen and enter the next process.
Structure of jaw crusher
Details Images
Working Principle
Our Advantages
*
The machine has a large crushing ratio, uniform product size, simple structure, convenient maintenance, can crush the compressive strength of a variety of materials
* First-class technology, reliable pre-sale customer service quality. The products meet European CE certification standards.
* Model for the latest products, a wide range of applications, with a compact structure, long service life, and high work efficiency.
*
High capacity, less costly ,Easy to install and
Energy saving, one jaw crusher can save energy of 15%-30%
Packing And Delivery
Product Paramenters
|
Model
|
Feeder Opening Size(mm)
|
Max. Feeding Size (mm)
|
Discharging Opening Size(mm)
|
Capacity (t/h)
|
Motor Power (kw)
|
Overall Dimension (mm)
|
|
PE150x250
|
150x250
|
130
|
10-45
|
1-5
|
5.5
|
896x745x935
|
|
PE200x300
|
200x300
|
180
|
15-50
|
2-6
|
7.5
|
910x750x990
|
|
PE200x350
|
200x350
|
180
|
18-70
|
3-10
|
7.5
|
1000x870x990
|
|
PE250x400
|
250x400
|
210
|
25-60
|
5-20
|
15
|
1215x1240x1210
|
|
PE400x600
|
400x600
|
350
|
40-90
|
15-65
|
30
|
1700x1750x1680
|
|
PE500x750
|
500x750
|
425
|
50-100
|
40-130
|
45
|
2150x1900x1950
|
|
PE600x900
|
600x900
|
500
|
60-125
|
90-180
|
55
|
2500x2010x2350
|
|
PE750x1060
|
750x1060
|
630
|
60-150
|
110-380
|
110
|
2630x2310x3110
|
|
PE900x1200
|
900x1200
|
750
|
95-165
|
220-450
|
132
|
3720x2850x3250
|
|
PE1000x1200
|
1000x1200
|
850
|
200-300
|
280-560
|
160
|
3820x2850x3250
|
|
PE1200x1500
|
1200x1500
|
1020
|
150-300
|
400-800
|
220
|
3710x3446x4075
|
|
PE1500x1800
|
1500x1800
|
1200
|
210-360
|
520-1100
|
280
|
5100x4700x4300
|
|
PEX150x750
|
150x750
|
120
|
10-40
|
5-16
|
15
|
1310x1118x1145
|
|
PEX250x750
|
250x750
|
210
|
15-50
|
15-30
|
22
|
1440x1751x1515
|
|
PEX350x750
|
350x750
|
300
|
15-50
|
18-40
|
30
|
1485x1680x1648
|
|
PEX250x1000
|
250x1000
|
210
|
15-60
|
15-52
|
30
|
1730x1950x1400
|
|
PEX250x1200
|
250x1200
|
210
|
15-60
|
20-60
|
37
|
1730x2150x1400
|
|
PEX300x1300
|
300x1300
|
250
|
25-60
|
30-105
|
55
|
2000x2320x1730
|
