Quick Details
-
Voltage:
-
AC220V/380V/50HZ
-
Dimension(L*W*H):
-
950*850*1600mm
-
Warranty:
-
1 years
-
Weight:
-
120KG
-
Power:
-
1.5kw watercooling spindle
-
Certification:
-
CE
-
Working area:
-
300*300*170mm
-
Power for spindle:
-
0.8kw/1.5kw /2.2 kw spindle
-
Cooling spindle:
-
watercooling spindle
-
Motor:
-
Servi motor or stepper motor
-
Ritary device:
-
80*300mm
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MITECH
-
Model Number:
-
MITECH-3030
-
Voltage:
-
AC220V/380V/50HZ
-
Dimension(L*W*H):
-
950*850*1600mm
-
Warranty:
-
1 years
-
Weight:
-
120KG
-
Power:
-
1.5kw watercooling spindle
-
Certification:
-
CE
-
Working area:
-
300*300*170mm
-
Power for spindle:
-
0.8kw/1.5kw /2.2 kw spindle
-
Cooling spindle:
-
watercooling spindle
-
Motor:
-
Servi motor or stepper motor
-
Ritary device:
-
80*300mm
Jade carving 3030 mini cnc router
mini cnc router features :
1.MINI 3030 style is an unique CNC engraver , which is designed for 3D basso-relievo in mahogany, classical furnitures.And it has high precision , fast speed, it can meet the needs of cutting flowers completely.
2.X axis are dustproof, the lathe bed is cast wholly. It is stable, durable, no deshape, high precision location.
3.Internagonal advanced DSP handle(Weihong system optional), a way to break memory, produce on accident (break) or next day .
4. TBI ball screw rod and round rail, original screw nut, imported linear and square rail. Air-cooled 1.5kw spindle motor
- -------------------------------------------------------------------------------
Rotary axis on the cnc router for different round materials processing
--------------------------------------------------------------------------------
Cooling for different jade, hard stone materials workings
--------------------------------------------------------------------------------
The cnc router install servo motor, guarantee the machine have high precision on different jade carving works.
--------------------------------------------------------------------------------
Jade carving cnc router parameters:
|
Description |
Parameter |
|
X,Y,Z Working Area |
300x300x170mm |
|
Table Surface |
Aluminum |
|
X, Z Structure |
Ball Screw |
|
Y Structure |
Hiwin Rail Linear Bearings or Ball Screw |
|
Max.Rapid Travel Rate |
8000mm/min |
|
Max.Working Speed |
6000mm/min |
|
Spindle Power Motor |
1.5Kw self cooling spindle |
|
Spindle Speed |
0-24000RPM |
|
Drive Motors |
Stepper system |
|
Working Voltage |
AC220V/50/60Hz/AC380V 50HZ |
|
Command Language |
G code |
|
Operating System |
DSP System (Option:NCstuido) |
|
Interface |
USB |
|
Flash Memory |
128M(U Disk) |
|
Collet |
ER16 |
|
X,Y Resolution |
<0.01mm |
|
Software Compatability |
Type3 software, Ucancam software, (Option:Artcam software) |
|
All parameters above subject to change without prior notice |
|
Mini cnc router applications:
1.
Wood working
:Solid wave board process,door of cabinet,wooden door,artistic wooden door ,no-paint door,avoid wind,process of the artistic window,shoes cleaning machine,the cabinet of the playing machine and the board,mahjong table,computer table .
2.
Advertising
:Advertising board,Label design,Acrylic cutting,model, of the multi material decoration products.
3.
Model industry
:It can engrave on the metal materials such as copper, aluminum ,iron etc and non-mental materials such as man-made marble, sand, plastic board PVC materials, wood board etc.
4.
Other field
:It can engrave many image, embossment,and widely used in artistic industry.
CE Certification is required for all recreational boats entering or being sold in the European Union. Manufacturers must test and document to ensure conformity to all applicable European directives and requirements. CE certification is obtained from Notified Bodies, organizations that are recognized by European states to conduct CE assessments and issue CE certification documents
General principles of the CE marking
- The CE marking shall be affixed only by the manufacturer or his authorised representative.
- By affixing or having affixed the CE marking, the manufacturer indicates that he takes responsibility for the conformity of the product with all applicable requirements set out in the relevant Community harmonisation legislation providing for its affixing.
- The CE marking shall be the only marking which attests the conformity of the product with the applicable requirements of the relevant Community harmonisation legislation providing for its affixing.
Package: Humidity-Proof Cloth Above Wooden Case,Oil Covered with Film on Machine Transmission, Steel Tubes On&Under Wooden Case.
Shipping: Safely and saving by sea
1.FOB----The nearest port is Qingdao port,and we can also delivery the machine to other port according to your request.
2.CIF-------Please tell me your destination port when you need CIF price.
3.If you need others, please tell me and I’m pleasure to do for you.
1.Technical support by phone, e-mail or MSN around the clock
2.Friendly English version manual and operation video CD disk
3.7-15 working days after down payment or full payment
4.Machine will be adjusted before it is delivered , operation disk/CD was included.
5.Engineers available to service machinery overseas, seller and buyer discuss the charges
