Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CAN OEM
-
Model Number:
-
C03H4
-
Warranty:
-
12 Months
-
Product Name:
-
Automotive Diagnostic Tool
-
Function:
-
Find and Clear Trouble Code
-
Language:
-
Multi-language
-
Keywords:
-
car scanner,car code reader,diagnostic tools,obd2 scanner
-
Item Type:
-
Universal Diagnostic Scanner
-
Certification:
-
CE FCC ROHS
-
Color:
-
black
-
Application:
-
Works on most gasoline vehicles after 1996
-
Update:
-
Latest
-
Performance:
-
Fast Speed Stable Function
Quick Details
-
Car Fitment:
-
Bajaj
-
Voltage:
-
9-16v
-
Applicable Models:
-
For most gasoline car after 1996
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CAN OEM
-
Model Number:
-
C03H4
-
Warranty:
-
12 Months
-
Product Name:
-
Automotive Diagnostic Tool
-
Function:
-
Find and Clear Trouble Code
-
Language:
-
Multi-language
-
Keywords:
-
car scanner,car code reader,diagnostic tools,obd2 scanner
-
Item Type:
-
Universal Diagnostic Scanner
-
Certification:
-
CE FCC ROHS
-
Color:
-
black
-
Application:
-
Works on most gasoline vehicles after 1996
-
Update:
-
Latest
-
Performance:
-
Fast Speed Stable Function
Specification
|
Product name
|
Car Diagnostic Tool
|
Warranty
|
12 Months
|
|
Model No.
|
C03H4
|
Working Voltage
|
9v-16v
|
|
Product Type
|
Code readers / ELM 327/ OBD2
|
Working Current
|
16mA
|
|
Hardware Version
|
V1.5
|
Operating environment
|
-40~80℃
|
|
Communication Mode
|
BT 4.0
|
Packing
|
PE packing
|
|
Chip
|
China made chip
|
Material
|
Plastic
|
|
Software platform
|
Android/
IOS
/Windows
|
Connector
|
OBD2 16-pin standard plug
|
|
APP
|
IOS(Car Scanner, OBD Auto Doctor)
Android（Torque）
|
Color
|
Black
|
|
Highlights
|
Newest, stable and good price
|
Size
|
45mm x25mmx75mm
|
Big Sales, 20% off
price compared with before
from 1st, October to 30th, October,
for all new customer can get
1pc free samples,
pls contact our sales for the sample.
Highlights
*
Newest product with low price
*
Domestic chip, stable transmission
*
Laser engraving OR code for download software, makes life more convenient
*
Novel design and portable
Product Description
（1）Features
* The Newest
* Low price
* Works on most gasoline vehicles after 1996
* Domestic chip, stable transmission
* Support IOS Android Windows system
* Laser engraving OR code for download software, makes life more convenient
* Novel design and portable
* Supports 9 protocols
* The Newest
* Low price
* Works on most gasoline vehicles after 1996
* Domestic chip, stable transmission
* Support IOS Android Windows system
* Laser engraving OR code for download software, makes life more convenient
* Novel design and portable
* Supports 9 protocols
(2) Functions
* Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
* Clear trouble codes and turn off the MIL ("Check Engine" light)
* Display current sensor data, including:
* Engine RPM
* Calculated Load Value
* Coolant Temperature
* Fuel System Status
* Vehicle Speed
* Short Term Fuel Trim
* Long Term Fuel Trim
* Intake Manifold Pressure
* Timing Advance
* Intake Air Temperature
* Air Flow Rate
* Absolute Throttle Position
* Oxygen sensor voltages/associated short term fuel trims
* Fuel System status
* Fuel Pressure
* Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
* Clear trouble codes and turn off the MIL ("Check Engine" light)
* Display current sensor data, including:
* Engine RPM
* Calculated Load Value
* Coolant Temperature
* Fuel System Status
* Vehicle Speed
* Short Term Fuel Trim
* Long Term Fuel Trim
* Intake Manifold Pressure
* Timing Advance
* Intake Air Temperature
* Air Flow Rate
* Absolute Throttle Position
* Oxygen sensor voltages/associated short term fuel trims
* Fuel System status
* Fuel Pressure
(3)Support 9
Protocols
*
SAE J1850 PWM (41.6Kbaud)
*
SAE J1850 VPW (10.4Kbaud)
* ISO9141-2(5 baud init, 10.4Kbaud)
* ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
* ISO14230-4 KWP (fast init, 10.4 Kbaud)
* ISO15765-4 CAN (11bit ID, 500 Kbaud)
* ISO15765-4 CAN (29bit ID, 500 Kbaud)
* ISO15765-4 CAN (11bit ID, 250 Kbaud)
* ISO15765-4 CAN (29bit ID, 250 Kbaud)
* ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
* ISO14230-4 KWP (fast init, 10.4 Kbaud)
* ISO15765-4 CAN (11bit ID, 500 Kbaud)
* ISO15765-4 CAN (29bit ID, 500 Kbaud)
* ISO15765-4 CAN (11bit ID, 250 Kbaud)
* ISO15765-4 CAN (29bit ID, 250 Kbaud)
（4）
Support OEM & ODM (Optional)
* OEM Your name
* OEM Your Product label
* OEM Your Packing box, manual
* OEM Your Product shell silk-screen
* OEM Your Product shell color / shape
* OEM Your Product firmware development, feature upgrade
* OEM Your name
* OEM Your Product label
* OEM Your Packing box, manual
* OEM Your Product shell silk-screen
* OEM Your Product shell color / shape
* OEM Your Product firmware development, feature upgrade
（5）
Package Includes
OBD2 Car Scanner*1
PE bag*1
PE bag*1
Certifications
All our Products has been proved by CE, Rohs, FCC, and Some products have been tested by Customers, which also passed all Test by SGS, We have all Test Report for our products, Quality is our biggest Features.
Product packaging & Shipping
1. What is the shipment way?
·Express company like DHL,TNT,UPS, Fedex, EMS (Door to Door service), by air company;
·By sea (LCL or whole container shipment), you can choose the one you prefer!
2. If the price include duty?
·Usually the price we quote without the duty in your country, as different country duty rate different, but to some countries, we will send by a special line which can with duty (e.g. European special line), please contact with us if you want to need more.
