Quick Details
-
Brand Name:
-
TUNERSYS
-
Model Number:
-
FP+9000
-
Dimension (L x W x H):
-
49 X 51 X 9 cm
-
Certification:
-
FCC, CE, ROHS
-
Frequency response (1W, 80ohms)+0/-3dB:
-
6.8Hz-34.2kHz
-
4 Ω output power:
-
3000W X 2 Channel
-
Total harmonic distortion:
-
1KHz < 0.05%
-
Signal-to-noise ratio S/N rate:
-
>112dBA
-
Input sensitivity:
-
23, 26, 29, 32, 35, 38, 41, 44dB
-
Input impedance:
-
20K Ω/balance
-
Damping factor:
-
> 2000
-
Resolution Crosstalk:
-
>70
-
Protection:
-
Short circuit & overload protection
Quick Details
-
Power:
-
6000W
-
Frequency Range (Hz):
-
6.8Hz-34.2kHz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TUNERSYS
-
Model Number:
-
FP+9000
-
Dimension (L x W x H):
-
49 X 51 X 9 cm
-
Certification:
-
FCC, CE, ROHS
-
Frequency response (1W, 80ohms)+0/-3dB:
-
6.8Hz-34.2kHz
-
4 Ω output power:
-
3000W X 2 Channel
-
Total harmonic distortion:
-
1KHz < 0.05%
-
Signal-to-noise ratio S/N rate:
-
>112dBA
-
Input sensitivity:
-
23, 26, 29, 32, 35, 38, 41, 44dB
-
Input impedance:
-
20K Ω/balance
-
Damping factor:
-
> 2000
-
Resolution Crosstalk:
-
>70
-
Protection:
-
Short circuit & overload protection
Product Description
Title goes here.
ALL channels drive output power (THD=1%) for each channel with resistive load under stable voltage and frequency supply conditions of 220V-50Hz
8 Ω output power/single channel 8 Ω output power 1600W
4 Ω output power/single channel 4 Ω output power 3000W
2 Ω output power/single channel 2 Ω output power 4500W
8 Ω bridge/single channel 8 Ω bridge power 6000W
4 Ω bridge/single channel 4 Ω bridge power 9000W
Frequency response (1W, 80ohms)+0/-3dB 6.8Hz-34.2kHz
Total harmonic distortion 1KHz ＜ 0.05%
Signal-to-noise ratio S/N rate>112dBA
Damping factor ＞ 2000
Resolution Crosstalk>70
Input sensitivity 23, 26, 29, 32, 35, 38, 41, 44dB
Input impedance 20K Ω/balance
Output circuit FTD class
Cooling four fans, airflow from the front panel to the rear panel, stepless wind speed, according to the temperature Power supply
requirements: Power AC110V/50Hz 60Hz, AC220V/50Hz 60Hz, AC240V/50Hz 60Hz, (customized) Product dimension (mm) 483mm × 396mm × 88mm
Product packaging dimension (mm): 580 × five hundred and sixty × two hundred Gross weight G.W: 14.65 kg
requirements: Power AC110V/50Hz 60Hz, AC220V/50Hz 60Hz, AC240V/50Hz 60Hz, (customized) Product dimension (mm) 483mm × 396mm × 88mm
Product packaging dimension (mm): 580 × five hundred and sixty × two hundred Gross weight G.W: 14.65 kg
FP is an extremely high power amplifier with beautiful sound, high efficiency, high transparency, and a complete multi-directional protection system. It has stable performance, low impedance, high temperature resistance, and finer sound quality compensation. FP series amplifier. The FP series mode with a frame size of 2U inherits TD class technology while maintaining excellent sound quality at the AB class output level, creating a new reference standard for touring audio power amplification.
High power output compact in a 2U chassis
Elastic configuration of 7 modes to adapt to any application
Available in 2-channel/4-channel versions
A complete set of protection functions to ensure the reliability and durability of touring performances under extreme conditions
Nomad Link network monitoring (module included as standard)
All channels bridgeable -6dB comprehensive automatic compensation
TD output, high efficiency and transparency
笔记
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
TUNERSYS
|
|
Model Number
|
FP+9000
|
|
Power
|
6000W
|
|
Frequency Range (Hz)
|
6.8Hz-34.2kHz
|
|
Dimension (L x W x H)
|
49 X 51 X 9 cm
|
|
Certification
|
FCC, CE, ROHS
|
|
Frequency response (1W, 80ohms)+0/-3dB
|
6.8Hz-34.2kHz
|
|
4 Ω output power
|
3000W X 2 Channel
|
|
Total harmonic distortion
|
1KHz < 0.05%
|
|
Signal-to-noise ratio S/N rate
|
>112dBA
|
|
Input sensitivity
|
23, 26, 29, 32, 35, 38, 41, 44dB
|
|
Input impedance
|
20K Ω/balance
|
|
Damping factor
|
> 2000
|
|
Resolution Crosstalk
|
>70
|
|
Protection
|
Short circuit & overload protection
|
Packing & Delivery
Size: 483mm x 505mm x 90mm
Weight: 26kg
