Quick Details
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Egood
-
Model Number:
-
TYPE 65 80 100
-
Track:
-
Anodized aluminum 6063-T6
-
Carrier materials:
-
Imported POM
-
Main frame:
-
Anodized aluminum 6063-T6
-
Carrier overload:
-
225--1300 kg
-
Partition thickness:
-
65, 80, 100mm
-
Sound insulation:
-
Max 53 db
-
Height:
-
Max 17 meter
-
Rockwool infill:
-
55kg/m3
-
Base board:
-
9/12mm thickness plywood/MDF
-
Finishing option:
-
Melamine ,fabric , leather, HPL, wall paper,etc
-
Type:
-
movable partition
Quick Details
-
Door Material:
-
Aluminum Alloy
-
Main Material:
-
Polymer
-
Application:
-
Hotel
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Egood
-
Model Number:
-
TYPE 65 80 100
-
Track:
-
Anodized aluminum 6063-T6
-
Carrier materials:
-
Imported POM
-
Main frame:
-
Anodized aluminum 6063-T6
-
Carrier overload:
-
225--1300 kg
-
Partition thickness:
-
65, 80, 100mm
-
Sound insulation:
-
Max 53 db
-
Height:
-
Max 17 meter
-
Rockwool infill:
-
55kg/m3
-
Base board:
-
9/12mm thickness plywood/MDF
-
Finishing option:
-
Melamine ,fabric , leather, HPL, wall paper,etc
-
Type:
-
movable partition
Technical data of Type 65 movable partition :
| Model |
Weight
(kg/m) |
Fire Rating(min) | STC Performance | Specification | Carrier | |||||
|
Thickness
(mm) |
Width(mm) | Height(mm) | Top Seal(mm)/ Pressure(kg) |
Bottom Seal(mm)/ Pressure(kg) |
LCP stretch (mm) | |||||
| EG65-32 | 22 | 60 | 32db | 65 | 680-1212 | 2000-4500 | 22.5/35 | 22.5/35 | 140 |
60#
65# 80# |
| EG65-38 | 27 | 60 | 38db | 65 | 680-1212 | 2000-4500 | 22.5/35 | 22.5/35 | 140 | |
| EG65-45 | 35 | 60 | 45db | 65 | 680-1212 | 2000-4500 | 22.5/35 | 22.5/35 | 140 | |
Technical data of Type 80 movable partition :
| Model |
Weight
(kg/m) |
Fire Rating(min) | STC Performance | Specification | Carrier | |||||
|
Thickness
(mm) |
Width(mm) | Height(mm) | Top Seal(mm)/ Pressure(kg) | Bottom Seal(mm)/ Pressure(kg) | LCP stretch (mm) | |||||
| EG80-40 | 30 | 60 | 40db | 80 | 680-1212 | 2000-5500 | 22.5/35 | 22.5/35 | 140 |
60#
80# 100# |
| EG80-45 | 38 | 60 | 45db | 80 | 680-1212 | 2000-5500 | 22.5/35 | 22.5/35 | 140 | |
| EG80-48 | 47 | 60 | 48db | 80 | 680-1212 | 2000-5500 | 22.5/35 | 22.5/35 | 140 | |
Technical data of Type 100 movable partition :
| Model |
Weight
(kg/m) |
Fire Rating(min) | STC Performance | Specification | Carrier | |||||
|
Thickness
(mm) |
Width(mm) | Height(mm) | Top Seal(mm)/ Pressure(kg) | Bottom Seal(mm)/ Pressure(kg) | LCP stretch (mm) | |||||
| EG100-43 | 38 | 60 | 43db | 100 | 680-1219 | 2000-7500 | 30/40 | 30/40 | 140 |
60#
|
| EG100-48 | 46 | 60 | 48db | 100 | 680-1219 | 2000-7500 | 30/40 | 30/40 | 140 | |
| EG100-53 | 55 | 60 | 53db | 100 | 680-1219 | 2000-7500 | 30/40 | 30/40 | 140 | |
|
Egood offers products and service with the end user in mind. We build in features that provide benefits to the owner over the life of the partition. Features such as protective edge trim will keep your partitions looking good for many years to come.
|
