Quick Details
-
Brand Name:
-
www.rubbervalve.com
-
Product name:
-
Diaphragm valve
-
Pressure:
-
Low Pressure
-
Material:
-
Food Grade Silicone
-
Standard or nonstandard:
-
standard and customization
-
Color:
-
Customized Color
-
Temperature of media:
-
Normal Temperature
-
Certificate:
-
ISO9001:2015,13485,Biocompatibility
Quick Details
-
Port Size:
-
See below drawing
-
Place of Origin:
-
Fujian, China
-
Model Number:
-
CJT017
-
Brand Name:
-
www.rubbervalve.com
-
Product name:
-
Diaphragm valve
-
Pressure:
-
Low Pressure
-
Material:
-
Food Grade Silicone
-
Standard or nonstandard:
-
standard and customization
-
Color:
-
Customized Color
-
Temperature of media:
-
Normal Temperature
-
Certificate:
-
ISO9001:2015,13485,Biocompatibility
Water treatment small mini air fuel one way silicone check non return relief control diaphragm valve
|
Part No. |
Material |
Type |
Opening Pressure |
Back Pressure |
Port Size/Tube ID |
|
CJT017 |
ABS+SILICONE |
Diaphragm |
0-1Kpa |
<=300Kpa |
1/4(6.4mm) |
|
Available Sizes |
1/16(1.6mm)
,
1/8(3.2mm)
,
3/16(4.8mm)
,
1/4(6.4mm)
,
|
||||
|
Optional Body Material |
ABS,PP,PC,PA66,PVDF,etc. |
||||
|
Optional Material |
Silicone/VMQ,Viton/FKM,Fluorosilicone/
|
||||
|
Port Size |
Accessories Introduction(OD and ID) |
Applicable Accessories(Hose/tube/Pipe Size) |
|
|
Silicone |
TPU |
||
|
1/8”
|
OD:4.4 ID:1.9 |
OD:6 ID:3 |
OD:5.5 ID:3.5 |
|
3/16”
|
OD:6 ID:3.1 |
OD:7.5 ID:4.5 |
OD:7 ID:5 |
|
1/4 ”
|
OD:7.8 ID:3.1 |
OD:9 ID:6 |
OD:9 ID:7 |
|
5/16”
|
OD:9.5 ID:6.5 |
OD:11 ID:8 |
OD:10.5 ID:8.5 |
|
3/8”
|
OD:10.6 ID:6.5 |
OD:12 ID:9 |
OD:11.5 ID:9.5 |
|
According to different uses, our company can provide matching parts that meet NSF, ROSH and other standards. |
|||
Product selling point advantages:
1. Simple structure
2. Can be used for gas and liquid
3. Complete specifications
4. Comparative cost advantage
