Quick Details
-
Scan Speed:
-
350 ±50 scans/second
-
Brand Name:
-
winson
-
Place of Origin:
-
Guangdong, China
-
Interface Supported:
-
USB HID KEYBOARD/USB
-
Input Voltage:
-
DC 5V±10%
-
Current:
-
Max:135mA
-
Image Sensor:
-
CMOS Array Sensor
-
Sensor Resolution:
-
648X488 Pixels
-
Light Source:
-
White LED
-
Scanning Angle:
-
Pitch angle:±60°;Skew angle:±60°;Tilt angle:±60°
-
Field of View:
-
34°(H),26°(V)
-
Min Resolution:
-
0.127/5mil(PCS 0.9)
Quick Details
-
Type:
-
Barcode Scanner
-
Scan Element Type:
-
CMOS
-
Optical Resolution:
-
640x480 pixels
-
Scan Speed:
-
350 ±50 scans/second
-
Brand Name:
-
winson
-
Place of Origin:
-
Guangdong, China
-
Interface Supported:
-
USB HID KEYBOARD/USB
-
Input Voltage:
-
DC 5V±10%
-
Current:
-
Max:135mA
-
Image Sensor:
-
CMOS Array Sensor
-
Sensor Resolution:
-
648X488 Pixels
-
Light Source:
-
White LED
-
Scanning Angle:
-
Pitch angle:±60°;Skew angle:±60°;Tilt angle:±60°
-
Field of View:
-
34°(H),26°(V)
-
Min Resolution:
-
0.127/5mil(PCS 0.9)
Product Description
Specification
|
Interface Supported
|
USB HID KEYBOARD/USB
|
|
Input Voltage
|
DC 5V±5%
|
|
Current
|
Max:220mA
|
|
Image Sensor
|
CMOS Array Sensor
|
|
Sensor Resolution
|
640 X 480 Pixels
|
|
Light Source
|
white LED
|
|
Aiming light source
|
RED LED
|
|
Decoding speed
|
60FPS
|
|
Scanning Angle
|
Pitch angle:±65°;Skew angle:±65°;Tilt angle:±360°
|
|
Field of View
|
36H),27V)
|
|
Min Resolution
|
4mil
|
|
Min .PCS value
|
〉20% UPC/EAN 13（13mil）
|
|
Language
|
Multiple Languages
|
|
Data Edition
|
Support for custom data output
|
|
Decode Capability
|
1D:EAN-13，EAN-8，UPC-A，UPC-E，ISSN，ISBN，CodaBar， Code 128，Code93，ITF-14，ITF-6，Interleaved 2 of 5， Industrial 2 of 5，Standard 2 of
5，Matrix 2 of 5，GS1 Databar(RSS)，Code 39，Code 11，MSI-Plessey， GS1-Composite 2D:QR Code，Data Matrix，PDF417，Micro PDF417，Micro QR， Aztec，Maxi Code，HanXin code |
|
Dimensions
|
90mm*65mm*170mm(L*W*H)
|
|
Weight
|
180g
|
|
Indicator
|
Beeper, LED
|
|
Temperature
|
-20°∽60°C (operation)
-40°∽70°C (storage) |
|
Humidity
|
Relative humidity: 5% to 95% (no condensation)
|
|
Shock Drop Test
|
1.5m drop onto concrete surface
|
