Quick Details
-
Brand Name:
-
XWS
-
Supplier Type:
-
factory supplier
-
Type::
-
consumer electronics pcba
-
Base Material::
-
FR-4
-
Min. Hole Size::
-
0.2mm
-
Surface Finishing::
-
HASL
-
Inpedence control tolerence::
-
±5%
-
Surface processing::
-
Immersion Tin
-
Service:
-
OEM Services Provided
-
Layer:
-
1-24layers
-
Silkscreen color:
-
Black.white.yellow.red.blue.green
-
Solder mask:
-
Green. Red. Blue. White. Black.Yellow
Quick Details
-
Model Number:
-
xws-125
-
Type:
-
pcba
-
Place of Origin:
-
GUA
-
Brand Name:
-
XWS
-
Supplier Type:
-
factory supplier
-
Type::
-
consumer electronics pcba
-
Base Material::
-
FR-4
-
Min. Hole Size::
-
0.2mm
-
Surface Finishing::
-
HASL
-
Inpedence control tolerence::
-
±5%
-
Surface processing::
-
Immersion Tin
-
Service:
-
OEM Services Provided
-
Layer:
-
1-24layers
-
Silkscreen color:
-
Black.white.yellow.red.blue.green
-
Solder mask:
-
Green. Red. Blue. White. Black.Yellow
Product Information
|
Item
|
Manufacturer Capability
|
Min. Track Space
|
0.075mm
|
|
Layer
|
1-30 Layers
|
External Cu Thickness
|
18um-210um(HOZ-6OZ)
|
|
Material Type
|
FR4, High-TG,Halogen Free, Rogers, Aluminum Base
|
Internal Cu Thickness
|
18um-210um(HOZ-6OZ)
|
|
Max. Panel Dimension
|
646*1200mm
|
Drilling Bit Size
|
0.15-6.5mm
|
|
Outline Tolerance
|
±0.1mm
|
Finished Hole Dimension
|
0.1-6mm
|
|
Board Thickness
|
0.6mm-6mm
|
Hole Tolerance
|
±0.05mm
|
|
Board Thickness Tolerance
|
±10%
|
Hole Position Tolerance
|
±0.05mm
|
|
Dielectric Thickness
|
0.075mm-2mm
|
Laser Drilling Hole Size
|
0.075mm
|
|
Min. Track Width
|
0.075mm
|
Aspect Ration
|
10:01
|
More favorable price 、More detailed introduction、More quality service
Please contact us
