Quick Details
-
Model Number:
-
YB(M)P
-
Coil Number:
-
2
-
Usage:
-
Power supply
-
Coil Structure:
-
Toroidal
-
Application:
-
Power Distribution System
-
Type:
-
Oil Immersed Transformer
-
Frequency:
-
50/60Hz
-
Standard:
-
IEC ANSI IEEE
-
Warranty:
-
3 Years
-
Cooling Method:
-
ONAN ONAF
-
Vector Group:
-
Dyn11/Yyn0/Yd11/YNd11
-
Rated capacity:
-
10KVA-50000KVA
-
Winding material:
-
Copper / Aluminum
-
Rated voltage:
-
11kV/22kV/33kV
-
Rated Primary Voltage:
-
20
-
Rated Secondary Voltage:
-
0.4
-
Power:
-
AC/AC
Quick Details
-
Phase:
-
Three
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
FIRST POWER
-
Model Number:
-
YB(M)P
-
Coil Number:
-
2
-
Usage:
-
Power supply
-
Coil Structure:
-
Toroidal
-
Application:
-
Power Distribution System
-
Type:
-
Oil Immersed Transformer
-
Frequency:
-
50/60Hz
-
Standard:
-
IEC ANSI IEEE
-
Warranty:
-
3 Years
-
Cooling Method:
-
ONAN ONAF
-
Vector Group:
-
Dyn11/Yyn0/Yd11/YNd11
-
Rated capacity:
-
10KVA-50000KVA
-
Winding material:
-
Copper / Aluminum
-
Rated voltage:
-
11kV/22kV/33kV
-
Rated Primary Voltage:
-
20
-
Rated Secondary Voltage:
-
0.4
-
Power:
-
AC/AC
Specification
|
Rated Capacity
|
Voltage Ratio
|
Vector Group
|
No-load Losses(kw)
|
Inpedence
|
|
30kva
|
380v/3kv/6kv/11kv/33kv
|
Dyn11/Yd11/Yyno
|
0.1
|
4%
|
|
50kva
|
380v/3kv/6kv/11kv/33kv
|
Dyn11/Yd11/Yyno
|
0.13
|
4%
|
|
100kva
|
380v/3kv/6kv/11kv/33kv
|
Dyn11/Yd11/Yyno
|
0.2
|
4%
|
|
200kva
|
380v/3kv/6kv/11kv/33kv
|
Dyn11/Yd11/Yyno
|
0.34
|
4%
|
|
315kva
|
380v/3kv/6kv/11kv/33kv
|
Dyn11/Yd11/Yyno
|
0.42
|
4%
|
|
500kva
|
380v/3kv/6kv/11kv/33kv
|
Dyn11/Yd11/Yyno
|
0.6
|
4%
|
|
1000kva
|
380v/3kv/6kv/11kv/33kv
|
Dyn11/Yd11/Yyno
|
1.15
|
4.5%
|
|
1250kva
|
6kv/11kv/33kv
|
Dyn11/Yd11/Yyno
|
|
4.5%
|
|
2500kva
|
11kv/33kv
|
Dyn11/Yd11/Yyno
|
2.3
|
|
|
4000kva
|
11kv/33kv
|
Dyn11/Yd11/Yyno
|
2.8
|
|
