Quick Details
-
Voltage:
-
380V, Customized
-
Power:
-
20.7KW
-
Dimension(L*W*H):
-
6*2*2.2m
-
Weight (KG):
-
2000
-
Marketing Type:
-
New Product
-
Product name:
-
Peanut Nutmeg Grain Drying Machine
-
Host material:
-
Stainless steel
-
Heating source:
-
Natural Gas
-
Function:
-
Drying food, vegetable, etc
-
Drying temperature:
-
40 - 120℃, Adjusted
-
Feature:
-
Continuous Peanut Nutmeg Grain Drying Machine
-
Application material:
-
Grain, spice, peanut, nutmeg, cereal, corn, seed, cocoa beans
-
Drying time:
-
0.5-5h
-
Evaporation capacity:
-
500-600kg/h
-
Usage:
-
Industrial
Quick Details
-
Type:
-
mesh belt dryer machine
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Baixin
-
Voltage:
-
380V, Customized
-
Power:
-
20.7KW
-
Dimension(L*W*H):
-
6*2*2.2m
-
Weight (KG):
-
2000
-
Marketing Type:
-
New Product
-
Product name:
-
Peanut Nutmeg Grain Drying Machine
-
Host material:
-
Stainless steel
-
Heating source:
-
Natural Gas
-
Function:
-
Drying food, vegetable, etc
-
Drying temperature:
-
40 - 120℃, Adjusted
-
Feature:
-
Continuous Peanut Nutmeg Grain Drying Machine
-
Application material:
-
Grain, spice, peanut, nutmeg, cereal, corn, seed, cocoa beans
-
Drying time:
-
0.5-5h
-
Evaporation capacity:
-
500-600kg/h
-
Usage:
-
Industrial
Peanut Dryer Machine Continuous Automatic Vegetable Nutmeg Drying Machine
Drying processing description:
1. Put the wet material on feeding device, The material through the homogenizer was spread evenly and entered from the top of the dryer;
2. The material is transported by multi-layer mesh belt from top layer to bottom layer in the oven;
3. At the same time,the heat source produce heat and come into the oven from the bottom,Because the lower pressure is greater than the upper pressure,the hot air naturally moves upward ,passing through each layer of the mesh belt, plus the movement and rolling of the material,Make the material fully contact with the hot air , fully heat exchange , and improve the drying efficiency. ;
4. After heat exchange, the moisture is evaporated from the top, and the material is discharged from the outlet after drying.
| Peanut Nutmeg Drying Machine | |||
| Type: 9m 4-layers gas heating mesh belt dryer | |||
| Complete equipment performance parameters | input capacity | 500-800kg/h | |
| material Spreading thickness | 50-200mm | ||
| heating source | 3.6m³-14.4m³ | ||
| Drying temperature | 20-120℃ | ||
| Drying time | 0.5-5h | ||
| Total power | 20kw | ||
| Performance parameters of each component | Component | size | Power |
| Dryer host | 9*2*2.5m | 1.5kw | |
| Feed conveyor | 5.44*2.06*0.66m | ||
| Discharge conveyor | 3.26*0.56m | 0.12kw | |
| Fan(air intake system) | 1.68*1.9*2.22m | 18.5kw | |
| gas furnace | 2.8*1.4*1.8m | ||
Drying Effect Show
multi layer belt d ryer m achine is a kind of continuous production drying equipment, the main heating way has electric , s tea m , natural gas, coal, wood etc.we can spread the material evenly in the feeding conveyor belt. The material is moved in the belt by the operation of the machine, and the hot air draws out the water vapor of the material. so as to achieve the purpose of drying.
The operation temperature is 40-120 degree centigrade. the temperature can adjust via the control panel, different heating source will provide different temperature , also will make the dryer time not same. this multi layer belt dryer machine can continuous feeding, automatic working can save hands and improve work efficiency.
there have more choice for the multi layer mesh belt dryer machine, you can according to your drying capacity and heating source to choose suitable machine.
we also can provide customize service , can according to your details requirement to design special machine for you.
The mesh belt dryer machine is suitable for food series, vegetable series, fruit series, pharmaceutical series, agricultural and sideline products of large-scale continuous dehydration drying. It is an ideal choice for large enterprises to dry fruits, vegetables, flower s, leaves, meat, pet snacks, herbs, spices, nuts, seeds, and seafood.
Your product is not listed above? We are ready to meet any new challenge! Contact us for free product testing!
1:High capacity: The mesh belt dryer has continuous automatic production, fast dehydration speed, short drying time and high output.
2.High quality: material can be maintained full of shape,bright,color.
3.Clean and sanitation : The entire material drying process is completed in a closed box, free from external pollution.
4. Intelligent and controllable: High degree of automation equipment,simple operation.Drying area, air pressure, air flow, drying temperature and belt running speed can be adjust.
5. Wide usage: Can be used for material from any field.
6. Flexible heat source selection: Coal,wood chips,natural gas,diesel,propane,electricity etc.
7: Flexible mobility,simple installation .
