Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers
Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers
Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers
Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers
Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers
Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers
Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers
Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers

Dual 8 Inch Line Array Sound Audio Equipment System High End Passive Two Way Church Speakers

FOB Reference Price: Get Latest Price
≥5 Pieces
US $610
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Brand Name:
TR.LIGE
Model Number:
TZ-228PA
Dimension (L x W x H):
250mm*700mm*433mm
Application:
Church
Type:
Passive
Color:
Customizable
Material:
Birch Plywood/Customizable
Function:
Voice
Channel:
2 way
Size:
2*8''
Packing:
Carton Box/Flight Cases/Wooden Shelf
Power Supply:
Other
Connector:
2x Speakon NL4MP

Quick Details

Power:
960W RMS/1920W Peak
Frequency Range (Hz):
70-20000Hz
Place of Origin:
Guangdong, China
Brand Name:
TR.LIGE
Model Number:
TZ-228PA
Dimension (L x W x H):
250mm*700mm*433mm
Application:
Church
Type:
Passive
Color:
Customizable
Material:
Birch Plywood/Customizable
Function:
Voice
Channel:
2 way
Size:
2*8''
Packing:
Carton Box/Flight Cases/Wooden Shelf
Power Supply:
Other
Connector:
2x Speakon NL4MP
Model:TZ-228PA
Drivers
HF:1×1.4"Voice-coil:3"
LF:2×8"Voice-coil:2"
Frequency (-10dB)
70-20000Hz
Dispersion(-6dB)
horizontal:110°Splay angle setting:0°-10°(1°increment)
Sensitivity(1m/1W)
HF:103dB/LF:99dB
maximum SPL
125.8dB Continuous/131.8dB Peak
Nominal Impedance
8 Ohm
Rated Power
960W RMS/1920W Peak
Crossover Frequency
1500Hz
Connectors
2x Speakon NL4MP
Material
High-quality double-layer birch plywood box
Mesh surface
High-strength steel mesh with hexagonal holes, plus special acoustically transparent sponge mesh
Finish
Environmental protection water-based paint
Handing Position
Dedicated hoisting system
Dimensions(H×Wx D)
250mm×700mm×433mm
Net Weight(Kg)
22.5
Cross weight(Kg)
24.7
Quality creates the future and restores the most authentic sound.
Professional casting quality, quality reaches the brand
TEL : 13535155768 WEB: www.baonaaudio.com Email: trangrenlige@gmail.com
TR.LIGE professional audio brand was founded in 2013. It is a manufacturer integrating R&D,manufacturing, sales and engineering design services. lts products include: stage professional speakers, linear array speakers, KTV private room speakers, conference system products,Power amplifier and peripheral electronic products, etc.
Applicable places: performances, performing arts bars, party bars, music restaurants, auditoriums.
Q1:What can you buy from us? A1: Speaker,loundspeaker ,amplifier,surround,mircophone Q2:Can I have a sample order for loudspeaker? A2: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q3: What about the lead time? A3:Sample needs 2-5 days, mass production time needs 3-4 weeks for order quantity more than
Q4:Is the shipping included in the product prices?
A4:NO,s hipping is calculated separately.
Q5:Do you provide OEM and ODM service?
A5:Yes, we have OEM and ODM project experience.
