Quick Details
-
Brand Name:
-
DINOS
-
Place of Origin:
-
zhejiang
-
Model Number:
-
DB25
-
Brakes - RR:
-
Single Piston Caliper, 190mm Disc
-
dirt bike Engine:
-
Four-stroke
-
Suspension Linkage:
-
Installed
-
Tires - FT:
-
70/100-17 Knobby Off Road Tire
-
Tires - RR:
-
90/100-14 Knobby Off Road Tire
-
L x W x H:
-
1520*740*970 mm
-
dirt bike Starting system:
-
electric start
-
Wheel - FT:
-
Steel rim FT: 1.60 x 17
-
Wheel - RR:
-
Steel rim , RR: 1.85 x 14
-
Brakes - FT:
-
Dual Piston Caliper, 220mm Disc
Quick Details
-
Displacement:
-
200-400CC
-
Max. Speed:
-
> 80km/h
-
Motor:
-
Brushless
-
Brand Name:
-
DINOS
-
Place of Origin:
-
zhejiang
-
Model Number:
-
DB25
-
Brakes - RR:
-
Single Piston Caliper, 190mm Disc
-
dirt bike Engine:
-
Four-stroke
-
Suspension Linkage:
-
Installed
-
Tires - FT:
-
70/100-17 Knobby Off Road Tire
-
Tires - RR:
-
90/100-14 Knobby Off Road Tire
-
L x W x H:
-
1520*740*970 mm
-
dirt bike Starting system:
-
electric start
-
Wheel - FT:
-
Steel rim FT: 1.60 x 17
-
Wheel - RR:
-
Steel rim , RR: 1.85 x 14
-
Brakes - FT:
-
Dual Piston Caliper, 220mm Disc
Details Images
Specification
|
ENGINE
|
|
|
|
|||
|
Engine Type:
|
250cc air Cooled ( Liquid cooled optional )
|
Fuel Delivery:
|
Carburetor 30mm
|
|||
|
Bore x Stroke:
|
65.5 x 62.2
|
Ignition:
|
CDI
|
|||
|
Compression Ratio:
|
9.3 : 1
|
Starting:
|
Kick & Electric Start
|
|||
|
DRIVE TRAIN
|
|
|
|
|||
|
Final Drive:
|
Chain - 520H
|
Transmission:
|
5-Speed
|
|||
|
Sprocket(s):
|
FT: 13T / RR: 47T
|
Clutch:
|
Manual
|
|||
|
|
|
|
|
|||
|
CHASSIS
|
|
|
|
Frame:
|
Seamless Central Tubular Steel Frame
|
|
|
Swing-Arm:
|
High Strength Steel
|
|
|
Suspension - FT:
|
Inverted Hydraulic Non-Adjustable, 51-54-830mm
|
|
|
Suspension - RR:
|
Coil Spring Shock Absorber, Non-Adjustable, 450mm Length
|
|
|
Suspension Linkage:
|
Installed
|
|
|
Brakes - FT:
|
Hydraulic, 240mm Disc, Dual Piston Caliper
|
|
|
Brakes - RR:
|
Hydraulic, 240mm Disc, Dual Piston Caliper
|
|
|
Tires - FT:
|
80/100-19 Knobby Off Road Tire
|
|
|
Tires - RR:
|
100/100-16 Knobby Off Road Tire
|
|
|
Wheel - FT:
|
1.60 x 19 Steel Rim (Aluminum - Optional)
|
|
|
Wheel - RR:
|
1.85 x 16 Steel Rim (Aluminum - Optional)
|
|
|
DIMENSIONS
|
|
|
|
|||
|
L x W x H:
|
1900 × 800 × 1210 mm
|
Ground Clearance:
|
310 mm
|
|||
|
Seat Height:
|
880 mm
|
Fuel Capacity:
|
6.5 Liters
|
|||
|
Wheelbase:
|
1280 mm
|
Dry Weight:
|
105 kg.
|
|||
|
LOADING
|
|
|
|
|||
|
20 Ft:
|
32 pcs
|
Package Weight:
|
137 kg.
|
|||
|
40 Ft:
|
66 pcs
|
Package Size:
|
1710 x 460 x 820 mm
|
|||
|
40 Hq:
|
99 pcs
|
|
|
|||
Exhibition
Packing & Delivery
To make sure our products will be delivered to our customers undamaged, every package method needs to go through impact test. We are to be sure no customers will suffer loss from shipping.
