Quick Details
-
Model Number:
-
DF-CWM-01
-
Product name:
-
Copper Woven Wire Mesh
-
Color:
-
Red Copper Color,Yellow,Bronze
-
Length:
-
15-100m/roll
-
Feature:
-
Wear-resisting
-
Width:
-
0.6-1.3m
-
Usage:
-
Liquid Filter
-
Mesh:
-
2-200 Mesh
-
Weave Style:
-
Plain Twill Dutch Weave
-
Hole shape:
-
Square
Quick Details
-
Material:
-
Brass Wire/Phosphor Bronze Wire/Copper Wire
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
DONGFU
-
Model Number:
-
DF-CWM-01
-
Product name:
-
Copper Woven Wire Mesh
-
Color:
-
Red Copper Color,Yellow,Bronze
-
Length:
-
15-100m/roll
-
Feature:
-
Wear-resisting
-
Width:
-
0.6-1.3m
-
Usage:
-
Liquid Filter
-
Mesh:
-
2-200 Mesh
-
Weave Style:
-
Plain Twill Dutch Weave
-
Hole shape:
-
Square
Woven Copper Wire Mesh / Bronze Wire Mesh / Brass Wire Mesh, Customizable Specifications, Free Sample
Copper mesh series products are available in copper wire mesh, bronze wire mesh, and brass wire mesh.
They look similar in appearance and color. Due to the different compositions of metal materials, each product has different characteristics and use effects.
Copper mesh products are widely used in building decoration, household, electrical, technology, and other industries.
As a leading manufacturer and wholesaler of wire mesh products, Dongfu Wire Mesh can provide a wide selection of materials, wire diameters, mesh sizes, and weave types of copper mesh products.
Note: This series of products are customized products, so the price on the page are for reference only.
Contact our professional team to get the latest price for your project.
Products detailed introduction:
Copper wire mesh is the highest copper content in the copper mesh products, with a copper content of 99.9%. It is soft, malleable, and has high electrical and thermal conductivity. As a result, it is popularly used as RFI shielding, in Faraday Cages, in roofing, in HVAC, and in numerous electrical-based applications.
| Main Material: | 99.999% Pure Copper Wire. |
| Wire Diameter Range: | 0.03-0.70mm. |
| Mesh Size Range: | Plain Weave: 5– 200 mesh, Twill Weave: Up to 250 mesh, Dutch Weave: Can be customized as required. |
| Width Range: | Usually, 0.914-3 m, can be cut according to customer requirements, the minimum is 3 mm. |
| Length Range: | Usually 30 m, up to 150 m. |
| Mesh Type: | Generally 30m/roll, various shapes can also be cut as required. |
Features & Use:
- Soft, easily soldered
- Ductile and malleable
- Excellent thermal and electrical conductivity
- 99%+ pure copper
Not only used in the electrical industry. Copper wire mesh is also popular in the field of architectural decoration due to its unique color and flexible and weldable characteristics.
Homeowners and designers choose copper wire mesh for residential projects such as gutter guards, insect screens, fireplace screens, or decorative wall panels. Artists, including sculptors, woodworkers, metal artisans, and architects prefer copper mesh due to its ability to form complex shapes.
Product photos:
Bronze is an alloy mainly composed of copper. Therefore, bronze wire mesh and copper wire mesh have many of the same characteristics, like malleability, durability, and ductility. The chemical composition of commonly used commercial bronze wire mesh is 90% Copper and 10% Zinc.
| Main Material: | Copper content 85%-90%, zinc content 5%-15%. |
| Wire Diameter Range: | 0.03-0.70mm. |
| Mesh Size Range: | Plain Weave: 5– 185 mesh, Twill Weave: Up to 500 mesh, Dutch Weave: Can be customized as required. |
| Width Range: | Usually, 0.914-3 m, can be cut according to customer requirements, the minimum is 3 mm. |
| Length Range: | Usually 30 m, up to 150 m. |
| Mesh Type: | Generally 30m/roll, various shapes can also be cut as required. |
Features & Use:
-
Sturdier than copper and antique brownish-red color.
-
Superior to brass in both strength and corrosion resistance.
-
90 % copper and 10 % zinc.
- Uses include highly technical to decorative.
Bronze woven wire mesh has stronger corrosion resistance and durability than brass wire mesh. And it has a unique antique brownish-red color, which is an important reason for the use of bronze wire mesh from various marine and military applications to a commercial and residential insect screen. Bronze wire mesh is not as flexible and ductile as copper woven wire mesh for industrial needs, so it is often used in filtration and separation applications.
Product photos:
Brass is another copper alloy made of copper and zinc. And like copper wire mesh, brass wire mesh is soft and malleable. But its corrosion resistance is not as good as bronze.
As a wire mesh, the most commonly available brass woven wire mesh is referred to as “270 yellow brass” and has a chemical composition of approximately 65% copper, 35% zinc. “260 high brass”, which consists of 70% copper and 30% zinc is also popular in the mesh industry, particularly on custom manufactured items.
| Main Material: | 270 Yellow Brass (65% copper + 35% zinc), 260 High Brass (70% copper + 30% zinc), Red Brass(80% copper + 20% zinc). |
| Wire Diameter Range: | 0.03-0.70mm. |
| Mesh Size Range: | Plain Weave: 6– 160 mesh, Twill Weave: Up to 280 mesh, Dutch Weave: Can be customized as required. |
| Width Range: | Usually, 0.914-3 m, can be cut according to customer requirements, the minimum is 3 mm. |
| Length Range: | Usually 30 m, up to 150 m. |
| Mesh Type: | Generally 30m/roll, various shapes can also be cut as required. |
Features & Use:
- Superior to copper abrasion resistance and tensile strength.
- 60-70% copper plus 30-40% zinc.
- Easily cut with hand tools.
- It can be soldered with lead or silver solder.
Zinc plays an important role in brass wire mesh, it increases the wear resistance and higher tensile strength of brass wire mesh. It also hardens the mesh, compared to its softer copper woven wire mesh counterpart. For these reasons, brass wire mesh is commonly used in filtration and separation applications. In most cases, industrial-grade brass woven wire mesh has a golden yellow color to it, and this unique color makes it appealing for use in architectural, decorative and even artistic applications. Like virtually all wire mesh and wire cloth, brass wire mesh is used in architectural, decorative and industrial applications.
Product photos:
As a leading manufacturer and wholesaler of wire mesh products, Dongfu Wire Mesh can provide a wide selection of materials, wire diameters, mesh sizes, and weave types of copper mesh products.
Note: This series of products are customized products, so the price on the page are for reference only.
Contact our professional team to get the latest price for your project.
