Quick Details
-
Voltage:
-
3P380V
-
Dimension(L*W*H):
-
2312*930*2130mm
-
Weight:
-
311 KG
-
UV curing machine:
-
cylinder
-
color:
-
green
-
After Warranty Service:
-
Video technical support
Quick Details
-
Type:
-
Punching Machine
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LC
-
Voltage:
-
3P380V
-
Dimension(L*W*H):
-
2312*930*2130mm
-
Weight:
-
311 KG
-
UV curing machine:
-
cylinder
-
color:
-
green
-
After Warranty Service:
-
Video technical support
Product Description
There is a certain difference between the UV curing process of circular products and the UV curing of flat products. Usually, circular products need to be printed with UV ink in the circumferential direction. Rotate while irradiating light to ensure UV curing effect. Curved surface UV curing machine is widely used in plastic packaging, cosmetics, washing products, pharmaceutical industry, glass packaging and other industries. Conical or frustum-shaped supports are installed on its conveyor belt, which can support the bottles and the speed can be adjusted. It is used in conjunction with semi-automatic curved screen printing machines, and is a very popular product for small and medium printing companies.
| M-2030UVS Cylinder UV Curing Machine | |
| Conveyer Materials, Width | Stainless,400mm |
| Wattage of lamp | simple, 4000W Halogen |
| Speed adjustment | Stepless speed |
| Cooling Device | Fan, 1pcs |
| Max Products height | 300mm |
| Usage | Electron, Hardware, Auto, Toys, Gifts, Plastics parts,Plastics products, House appliances, work of art, Stationery, Ornament, any Round and oval objects UC Drying ,cosmetic, sports apparatus .UV drying for UV ink . |
| Technical parameters | |
|
1.Bucket open diameter
of workpiece |
350mm |
| 2.Conveyor speed | 0~10m/min |
| 3.Total power | 7KW |
| 4.UV Lamp wattage | 4KW |
| 5. Products | 320mm |
| 6. Conveyer width | 400mm |
|
Performance : 1.Suitable for the UV Ink printing cure on various bottles and cylindrical substrate. 2.By adjusting its lighting angle, it can also be used in the UV Ink printing cure of flat or curved substrate; 3.Enclosure construction with conveyor. Apply half light (3KW) or full light (6KW) tubes, the distance is adjustable; 4.On the top of the machine equipped with an exhaust system, you can vent the inside heat of curing chamber . |
|
