ITEM
|
ZAY7045FG
|
ZAY7045
|
ZAY7032G
|
|
Max Face mill capacity
|
45mm
|
45mm
|
32mm
|
|
Max End mill capacity
|
80mm
|
80mm
|
63mm
|
|
End milling capacity
|
32mm
|
32mm
|
20mm
|
|
Max.distance from spindle nose to table
|
450mm
|
450mm
|
440mm
|
|
Min.distance from spindle axis to column
|
260mm
|
203.5mm
|
272.5mm
|
|
Spindle travel
|
130mm
|
130mm
|
130mm
|
|
Spindle taper
|
M.T.4 or R8
|
M.T.4 or R8
|
M.T.3 or R8
|
|
Step of spindle speed
|
6
|
12
|
6
|
|
Range of spindle speed 50Hz
|
80-1250 r.p.m
|
80-2080 r.p.m
|
80-1250 r.p.m
|
|
60Hz
|
95-1500 r.p.m
|
100-2500 r.p.m
|
95-1500 r.p.m
|
|
Swivel angle of headstock(perpendicularly)
|
90°
|
360°
|
360°/±90°
|
|
Table size
|
800×240mm
|
800×240mm
|
800×240mm
|
|
Forward and backward travel of table
|
175mm
|
175mm
|
175mm
|
|
Left and right travel of table
|
500mm
|
500mm
|
500mm
|
|
Motor Power
|
1.5KW(2HP)
|
1.5KW
|
0.75KW(1HP)
|
|
Net weight/gross weight
|
325kg/375kg
|
285kg/335kg
|
315kg/365kg
|
|
Packing size
|
770×880×1160m
|
1020×820×1160
|
770×880×1160mm
|
