- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
8385x3074x3400mm
-
Machine Weight:
-
6800 kg
-
Color:
-
Customized
-
Max.dumping height:
-
3750mm
-
Engine:
-
Steyr
-
Name:
-
electric snow blade loader
-
Model:
-
loader quick hitch
-
Local Service Location:
-
South Africa
-
After-sales Service Provided:
-
Field maintenance and repair service
Quick Details
-
Engine Brand:
-
weichai
-
Power:
-
Other
-
Brand Name:
-
TDER
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
8385x3074x3400mm
-
Machine Weight:
-
6800 kg
-
Color:
-
Customized
-
Max.dumping height:
-
3750mm
-
Engine:
-
Steyr
-
Name:
-
electric snow blade loader
-
Model:
-
loader quick hitch
-
Local Service Location:
-
South Africa
-
After-sales Service Provided:
-
Field maintenance and repair service
|
Model
|
|
|
ZBT18
|
ZBT30
|
ZBT50
|
|
|
Rated Load (kg)
|
|
KG
|
1800
|
3200
|
5000
|
|
|
Bucket Capacity
|
|
m³
|
1.0
|
1.8
|
2.7-4.0
|
|
|
Up digging Force
|
|
KN
|
Swing arm：52KN
Bucket：47KN |
100
|
≥170
|
|
|
Operating Weight
|
|
kg
|
5200
|
10800
|
17000
|
|
|
Max.Dumping Height
|
|
mm
|
2450
|
3060
|
3600
|
|
|
Max.Turning Angle
|
|
°
|
35
|
35
|
35
|
|
|
Max. Gradeability
|
|
°
|
57
|
28
|
28
|
|
|
Total cycle time
|
|
s
|
10
|
10.4
|
3.8
|
|
|
Overall Dimensions(L*W*H)
|
|
mm
|
2800*1920*6000
|
6970x2245x3330
|
8015*3000*3380
|
|
|
Parameter of Travel Motor
|
Motor Type
|
|
Permanent Magnet Synchronous Motor
|
Permanent Magnet Synchronous Motor
|
Permanent magnet synchronization
|
|
|
|
Motor Rated
|
kw
|
75
|
80
|
120
|
|
|
Parameter of Main Pump Motor
|
Motor Type
|
|
Permanent Magnet Synchronous Motor
|
Permanent Magnet Synchronous Motor
|
Permanent magnet synchronization
|
|
|
|
Motor Rated
|
kw
|
30
|
45
|
120
|
|
|
Battery
|
Rated Capacity of Battery
|
AH
|
202
|
202
|
228/456
|
|
|
|
Rated Energy Capacity
|
kWh
|
109.3K
|
200
|
141/282
|
|
|
|
Rated Voltage
|
V
|
541
|
541
|
540
|
|
|
|
Theoretical Service Life
|
|
over 8 years
|
over 8 years
|
4000 Cycles,Capacity fade<30%
|
|
|
|
|
|
|
|
|
|
After-services:
Tider industrial is committed to offer not only products with high quality and performance and competitive price, but also in-time delivery and comprehensive after-services. All the products purchased from Tider enjoy one year or 2000 hours (which occurs first) warranty. During the warranty period, if there is any part broken because of quality problem (except easy-damaged parts), the defective parts will be repaired or replaced free of charges.
1. Why choose us?
As a manufacturer, Tider industrial is committed to offer not only products with
high quality
and performance and
competitive price
, but also in-time delivery and
comprehensive 7/24 after-sale services
.
2. What is the product range of our factory ?
Tider industrial is a large-scale machinery manufacturing enterprise primarily specializes in supplying wheel loaders, forklift trucks and related attachments. We can also customize non-standard products according to customer's requirements.
3. What payment terms can we accept?
Normally 30% deposit is required in advance, 70% balance shall be settled before shipment. And 100% irrevocable L/C at sight with the terms we agreed can also be accepted.
4. What Certificates do we have?
All products meet with the
ISO9001 Quality System
and have acquired
CE certificate. EPA approval
will be available if needed.
5. How about our delivery time?
Usually it will take
15 to 30 days
after receiving your deposit. About standard products, we always have in stock and can deliver immediately. But customized products will take more time, depending on the requirements of your order.
6. Can we provide OEM service?
Tider industrial can provide customized products according to customers' requirements, both
OEM and ODM
are acceptable.
