Quick Details
-
Model Number:
-
EPM -C0F
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-20~60℃
-
Max. Current:
-
5A
-
Certification:
-
TUV CE
-
Model:
-
EPM -C0F
-
Size:
-
30.3*40.2*93.2
-
Contacts type:
-
1NC/1NO
-
Direct open force:
-
>60N
-
Warranty:
-
1 Year
-
Rated operating voltage:
-
AC400V
-
Brand:
-
ESPE
-
Rated insulation voltage:
-
300V
-
Key inserting direction:
-
front side of switch
Quick Details
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ESPE
-
Model Number:
-
EPM -C0F
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-20~60℃
-
Max. Current:
-
5A
-
Certification:
-
TUV CE
-
Model:
-
EPM -C0F
-
Size:
-
30.3*40.2*93.2
-
Contacts type:
-
1NC/1NO
-
Direct open force:
-
>60N
-
Warranty:
-
1 Year
-
Rated operating voltage:
-
AC400V
-
Brand:
-
ESPE
-
Rated insulation voltage:
-
300V
-
Key inserting direction:
-
front side of switch
Welcome to ESPE! EPMC0F 1NC/1NO Electromagnetic Lock Safety Door Switch IP65 AC400V Rated Operating Vlotages
Here we just show an example, please contact us for more models. You're special for us and deserve our special customization service.
- Cost-effective and high quality
- Quick delivery time
- Support ODM & OEM service
- Professional technical service support
- 20 years experience and Chinese benchmark factory
Product range: Safety light curtain, safety door switch, safety relay, measuring light curtain, vehicle separator, laser lidar, photoelectric sensor
| Model | EPM-C0F |
| Standard | IEC60947-5-1/ EN60947-5-1/ GB14048.5-2017 |
| Protection degree | IP65 (EN60947-5-1, except key hole) |
| Durability |
Mechnical 1,000,000 min Electrical 300,000 min |
| Rated insulation voltage (Ui) | 300v |
| Rated impulse withstand voltage (Uimp) | 4kV |
| Nomical discharge current (Ith) | 8A |
| Voltage type | AC-15 |
| Rated operating voltage (Ue) | AC400V |
| Rated operating current (Ie) | 2A |
| Rated conditional short-circuit current | 1000A |
| Direct opening force | 60N min |
| Direct opening travel | 10mm Min |
| Operating speed | 0.01-0.5/s |
| Operating frequency | Maximum 20 times/minutes |
| Operating temperature | -20-60 °C (with no freezing) |
| Operating humidity | 85%RH |
EPMC0F 1NC/1NO Electromagnetic Lock Safety Door Switch IP65 AC400V Rated Operating Vlotages
