Quick Details
-
Customized support:
-
OEM, ODM
-
Place of Origin:
-
China
-
Brand Name:
-
Shinelite
-
Model Number:
-
D305
-
Mechanical Life:
-
15 years
-
AC outlets quantity:
-
0
-
Product name:
-
Wall Switch
-
Size:
-
86*86mm
-
Material:
-
PC Panel
-
Certificate:
-
CE RoHS
-
Application:
-
General-Purpose
-
Color:
-
Gray Black Gold Customized
-
MOQ:
-
1000pcs
-
Package:
-
1pc/opp bag, 10pcs/box, 100pcs/ctn
-
Keyword:
-
Wifi Power Outlet Plugs
-
Function:
-
Electrical Outlet Connection
Quick Details
-
Max. Current:
-
20A, 45A
-
Max. Voltage:
-
220V
-
Network:
-
Normal
-
Customized support:
-
OEM, ODM
-
Place of Origin:
-
China
-
Brand Name:
-
Shinelite
-
Model Number:
-
D305
-
Mechanical Life:
-
15 years
-
AC outlets quantity:
-
0
-
Product name:
-
Wall Switch
-
Size:
-
86*86mm
-
Material:
-
PC Panel
-
Certificate:
-
CE RoHS
-
Application:
-
General-Purpose
-
Color:
-
Gray Black Gold Customized
-
MOQ:
-
1000pcs
-
Package:
-
1pc/opp bag, 10pcs/box, 100pcs/ctn
-
Keyword:
-
Wifi Power Outlet Plugs
-
Function:
-
Electrical Outlet Connection
The switch contacts are made of high-quality silver alloy material, which has a good performance against electric arc and melts weld. The on-off operations exceed 40000 times.
The socket is made of phosphor bronze, which has the character of good electrical conductivity and lasting elasticity.
|
Outline size: |
86x86mm |
|
Installation size: |
60 |
|
Material: |
Plastic |
|
Copper: |
QSn5.6-0.1 H62 Hpb59 |
Socket Specification
|
Lifetime |
≥5000 |
|
Heat-resistant |
100 • C / 1h |
|
Insulation Resistance |
≥5M Ω |
|
Damp Resistance |
48h > 5M Ω |
|
Temperature Raise |
≤ 45K |
|
Earthing Provision |
≤0.05M Ω |
|
Electric Strength |
2000 V ~1 min |
