5 Inch Flush Mount In Wall Android Screen POE Tablet

5 Inch Flush Mount In Wall Android Screen POE Tablet

FOB Reference Price: Get Latest Price

≥1 Pieces

US $119

≥100 Pieces

US $99

≥1000 Pieces

US $94

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Operating System:: Android 7.1

Type:: Tablet PC

Weight:: 0.5kg

Place of Origin:: Guangdong, China

Brand Name:: SIBO

Model Number:: Q5

CPU:: Quad-Core

Android System:: 7.1.1

Optional Function:: Proximity Sensor, NFC Reader, Zig-bee Coordinator

Optional Interfaces:: TTL UART, RS232, RS485, GPIO, 1 Wire

POE:: IEEE802.3af, 48V

Installation:: Standard European and US gang box; screw nut installation

Language:: Multi Languages Support

Color:: Black/White

Quick Details

Screen Size:: 5 inch

Memory Capacity:: 1gb

Display resolution:: 1280x720

Operating System:: Android 7.1

Type:: Tablet PC

Weight:: 0.5kg

Place of Origin:: Guangdong, China

Brand Name:: SIBO

Model Number:: Q5

CPU:: Quad-Core

Android System:: 7.1.1

Optional Function:: Proximity Sensor, NFC Reader, Zig-bee Coordinator

Optional Interfaces:: TTL UART, RS232, RS485, GPIO, 1 Wire

POE:: IEEE802.3af, 48V

Installation:: Standard European and US gang box; screw nut installation

Language:: Multi Languages Support

Color:: Black/White

Product Description

Product Name	5 Inch Flush Mount In Wall Android Screen POE Tablet
Material	Indusrtial standard material
Power Supply	DC-IN(12V); optional DC-IN(9V-36V), POE
Main Function	POE, proximity Sensor, NFC reader, Zig-bee coordinator
Interfaces	RJ45, Micro USB(OTG), TF slot, TTL UART(optional RS232, RS485), GPIO(optional 1 wire communication sensor)
Installation	European and US standard gang box installation
Warranty	12 months

5 Inch Flush Mount In Wall Android Screen POE Tablet :

-Android 7.1 OS with rooted right.

-IPS screen, resolution:1280x720

-POE, IEEE802.3af, 48V

- TTL UART, RS232, RS485, GPIO, 1 wire communication sensor

-Support source code to integrate with your software

- Bracket for wall mount

-Custom boot up logo

Details Images

SIBO 5'' POE Tablet For HVAC Control:

Nowadays, smart tablet with a small screen less than 5 inch is a trend for environment protection . SIBO 4.99 inch tablet Q5 is our newest model with full-view ips screen, resolution 1280x720. Tablet Q5 has optional proximity sensor and NFC reader, which will be provided source codes and demo apps for your software integration. Also the tablet can be powered by DC-IN or POE(IEEE802.3af, 48V). Zig-bee coordinator is the recommended function on this tablet for controlling devices in smart home such as lights, window curtains. As well as this 4.99 inch tablet has optional interfaces for device control: TTL UART (RS232 or RS485), GPIO (1 wire communication sensor). Meanwhile, tablet Q5 supports standard European and US gang box; screw nut installation.

Customized tablet in accordance with your requirements:

1.Support small quantity and sample order.

2.Sample lead time is 5-7 working days.

Micro USB(TOG) and TF slot on side, UBoot for reboot

	Default functions	Alternative options 1	Alternative options 2
J1	GPIO 1	-	-
J1		GND	-	-
J2	3.3V	3.3V	-
		GPIO 2	DATA(1 wire)	-
		GND	GND	-
J3	DC IN（12V）	DC IN (12-36V)	-
J3		GND	GND	-
J4	UART TX	RS232 TX	RS485+
		UART RX	RS232 RX	RS485-
		GND	GND	GND
J5	RJ45	POE RJ45	-

J6	-	NFC Reader	Zigbee Coordinator
J7	-	PS Sensor	-
J8	-	MIC and Sperker	MIC and Speaker + ECHO

Front dimension is 140x88mm, and the thickness is 15mm

Installation Instructions

Vertical Installation

Horizontal Installation

1. Standard European gang box

2. US gang box

3. Screw nut installation

Packing&Shipping

Packaging	10 units/ ctn
Carton dimension	28.5x27.8x31.5cm
Weight	7.5kg/ctn
Shipping	Fedex/DHL/UPS/TNT or your option
Delivery day	Sample:5-7 days, batch goods:20-25 days
Warranty	12 months

Company Introduction

About us:

Since established in 2001, Shenzhen SIBO Industrial & Development Co., Ltd already had an 18-year experience in tablet industry as a manufacturer. Right now, our mian product are 7'' , 9'' and 10.1'' custom tablets. With the good quality control and humanized customized service, SIBO company has already earned a good reputation from domestic and oversea. We will devote our expertise and technique to meet your business needs from designing to manufacuring the right products.

Our Services & Strength

* 18 Years Experiences in Tablet PC for Automation
* Competitive Price Directly From Manufacturer( Our Own Factory)
* Excellent Support for Software and Hardware Modification
* Services for Customized Logo and package
* Quick Response for after-sale Services
* On-time Delivery

FAQ

Question: Are you manufacturer?
Answer: Yes, we are professional manufacturer for intelligent control since established in 2001.

Question: What is your company mainly products?
Answer: Our mainly products are 5'', 7'', 9'' and 10.1'' tablet pc which applied for office reservation, time attendance, digital signage, access & security control, home automation, industrial control, energy & power management...

Question: What is the Minimum Order Quantity(MOQ)?
Answer: No quantity limited, sample order is acceptable.

Question: What is the lead time? (How long do you need to prepare my goods?)
Answer: 5-7 days for sample orders, 20-25 days for mass production orders(based on different quantities, OEM, etc.)

Question: How will you deliver my goods to me?
Answer: We ship by air and sea generally. In the mean time, we cooperate with international expresses such as DHL, UPS, FedEx, TNT to enable our customers to get their goods rapidly.

Question: How long do I need to wait before my goods arrive?
Answer: 3-5 days for international express.

Question: Can you put my brand name (logo) on these products?
Answer: Of course, OEM service is the most important part of our trade purpose.

Question: What service do you have?
Answer: We have full-technique support (offer sample app and original source code for RS485,GPIO, NFC, etc.)

Question: What is your warranty?
Answer: Our warranty is 1 year after delivery,SIBO pays high attention to after-sales service. For those out of warranty, we repair you without labor charge collection.

Question: What is your product quality?
Answer: 1. We promise to use the best (original) components to ensure our product in high level.
2.All tablet PC have 24 hours aging test.
3.All products will be carefully tested by our QC department.
