Quick Details
-
Application:
-
Office Building
-
Design Style:
-
Minimalist
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TianGe
-
Model Number:
-
E16-6, V16-6,E32-6,V32-6
-
Type:
-
Acoustic Panel
-
Material:
-
MDF
-
Width:
-
600/1200/1220 mm
-
Length:
-
800/1200/2400/2440 mm
-
Thickness:
-
12/15/18 mm
-
Base material:
-
standard, fire proof, eco-MDF
-
Finish:
-
melamine,veneer, metal
-
Model:
-
28/4,13/3,14/2,59/5
-
Fire rate:
-
B1
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
-
Project Solution Capability:
-
total solution for projects
-
Application:
-
Office Building
-
Design Style:
-
Minimalist
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TianGe
-
Model Number:
-
E16-6, V16-6,E32-6,V32-6
-
Type:
-
Acoustic Panel
-
Material:
-
MDF
-
Width:
-
600/1200/1220 mm
-
Length:
-
800/1200/2400/2440 mm
-
Thickness:
-
12/15/18 mm
-
Base material:
-
standard, fire proof, eco-MDF
-
Finish:
-
melamine,veneer, metal
-
Model:
-
28/4,13/3,14/2,59/5
-
Fire rate:
-
B1
| Standard Size | Length: 605/1210mm; Width: 605mm; Thickness: 12/15/18mm |
| More Size | Length: 600/1200/2400mm; Width: 600/1200mm; Thickness: 12/15/18mm |
| Wood surface | Melamine, natural veneer, fireproof board, spray paint, metal surface, technical veneer, leather surface, etc. |
| Basic Material | MDF board, environmental protection board, flame retardant board, black MgO board, white MgO board, red MgO board,carbon fiber board, solid wood board etc. |
| Structure | Holes are made from high-density basic board, and sound-absorbing black felt is attached to the back of the board. |
| Installation materials | Holes are made from high-density basic board, and sound-absorbing black felt is attached to the back of the board. |
| Installation materials | Light steel keel, 12 cm splint, sound-absorbing cotton, steel wire mesh, special keel, etc. |
| Environmental protection grade | E1 grade |
| Fire-proof grade | A grade or B1 grade |
| Service | Free samples,support customization |
| Application place | Gymnasium, multi-function hall, concert hall, grand theater, meeting room, lecture hall, home theater, hotel, etc. |
There are 6 basic materials:
Ordinary substrate material-Without fire rated; Red color base material-B1 grate fire rated;
Black color base material-B2 grade fire rated; Red MGO board-A grade fire rated;
Black MGO board-A grade fire rated; White MGO board-A grade fire rated. Application place: Gymnasium, multi-function hall, concert hall, grand theater, meeting room, lecture hall, home theater, hotel, etc.
