Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
Haoquan
-
Model Number:
-
MP-40r
-
Place of Origin:
-
Zhejiang, China
-
Horsepower:
-
65w
-
Structure:
-
magnetic pump
-
Cable Length:
-
1.5 M
-
Outlet Size:
-
20mm hose barb
-
Power:
-
65w
-
motor:
-
65w
-
Product name:
-
Magnetic Pump
-
Usage:
-
Chemical
-
Material:
-
Stainless Steel, Glass Fiber Reinforce Polypropylene
-
Color:
-
Green
Quick Details
-
Application:
-
Biofuel Industry, District Energy, Food and Beverage Industry, Industrial Utilities, Machining, Marine, Pharmaceutical industry, Washing and Cleaning, wastewater treatment
-
Pressure:
-
Other
-
Voltage:
-
110/220V, 110V/220V
-
Warranty:
-
1 year
-
Brand Name:
-
Haoquan
-
Model Number:
-
MP-40r
-
Place of Origin:
-
Zhejiang, China
-
Horsepower:
-
65w
-
Structure:
-
magnetic pump
-
Cable Length:
-
1.5 M
-
Outlet Size:
-
20mm hose barb
-
Power:
-
65w
-
motor:
-
65w
-
Product name:
-
Magnetic Pump
-
Usage:
-
Chemical
-
Material:
-
Stainless Steel, Glass Fiber Reinforce Polypropylene
-
Color:
-
Green
|
Model
|
Tube interface(mm)
|
|
Spiral interface(inch)
|
|
Max.Capacity
|
Max.Head
|
Power
|
Voltage
|
||||||||
|
|
Entrance
|
outlet
|
Entrance and exit
|
Live pipe
|
50/60Hz (L/min)
|
(m)
|
50/60Hz (w)
|
(v)
|
||||||||
|
MP-6R(M)
|
14
|
14
|
G 1/2
|
G 1/2
|
8/9
|
1/1.4
|
6
|
110/220
|
||||||||
|
MP-10R(M)
|
14
|
14
|
G 1/2
|
G 1/2
|
11/12
|
1.5/2.1
|
6
|
110/220
|
||||||||
|
MP-15R(M)
|
16
|
16
|
G 1/2
|
G 1/2
|
16/19
|
2.7/3.4
|
10
|
110/220
|
||||||||
|
MP-15RN
|
16
|
16
|
-
|
-
|
16/19
|
2.7/3.4
|
10
|
220
|
||||||||
|
MP-20R(M)
|
18
|
18
|
G1/2
|
G1/2
|
27/32
|
3.1/4.3
|
15
|
110/220
|
||||||||
|
MP-20RX
|
26
|
26
|
-
|
-
|
46/52
|
1.8/2.5
|
15
|
110/220
|
||||||||
|
MP-20RZ(M)
|
18
|
18
|
G 3/4
|
G 3/4
|
10/11
|
4.6/6.9
|
15
|
110/220
|
||||||||
|
MP-30R(M)
|
20
|
20
|
G 3/4
|
G 3/4
|
33/38
|
3.8/5.4
|
25
|
110/220
|
||||||||
|
MP-30RZ(M)
|
18
|
18
|
G 3/4
|
G 3/4
|
15/17
|
8/11
|
25
|
110/220
|
||||||||
|
MP-30RX(M)
|
26
|
26
|
G 1
|
G 1
|
62/72
|
2.9/4.1
|
25
|
110/220
|
||||||||
|
MP-40R(M)
|
20
|
20
|
G 3/4
|
G 3/4
|
45/52
|
4.6/6.5
|
65
|
110/220
|
||||||||
|
MP-40RX(M)
|
26
|
26
|
G 1
|
G 1
|
75/85
|
3.3/4.7
|
65
|
110/220
|
||||||||
|
MP-40RZ(M)
|
18
|
18
|
G 3/4
|
G 3/4
|
22/28
|
10/13.5
|
65
|
110/220
|
||||||||
|
MP-55R(M)
|
26
|
26
|
G 1
|
G 1
|
60/70
|
5.6/8.2
|
90
|
220/380
|
||||||||
|
MP-55RZ(M)
|
26
|
26
|
G 1
|
G 1
|
25/28
|
10/14
|
90
|
220/380
|
||||||||
|
MP-70R(M)
|
26
|
26
|
G 1
|
G 1
|
86/97
|
6.7/9.7
|
150/180
|
220/380
|
||||||||
|
MP-70RZM
|
20
|
20
|
G 3/4
|
G 3/4
|
40/43
|
14.3/20.3
|
150/180
|
220/380
|
||||||||
|
MP-100R(M)
|
26
|
26
|
G 1
|
G 1
|
120/130
|
8.6/11.6
|
250/265
|
220/380
|
||||||||
|
MP-100RX
|
-
|
-
|
G 1(1/4)
|
G 1(1/4)
|
170
|
9
|
250
|
220/380
|
||||||||
|
MP-120R
|
-
|
-
|
G 1(1/2)
|
G 1(1/2)
|
220
|
10.5
|
370
|
220/380
|
||||||||
|
MPH-400
|
-
|
-
|
G 1(1/2)
|
G 1(1/2)
|
260
|
12.5
|
400
|
220/380
|
||||||||
|
MPH-401
|
-
|
-
|
G 1(1/2)
|
G 1(1/2)
|
330
|
18
|
750
|
380
|
||||||||
|
MPH-422
|
-
|
-
|
G 2
|
G 1(1/2)
|
400
|
23
|
1500
|
380
|
||||||||
|
MPH-423
|
-
|
-
|
G 2
|
G 1(1/2)
|
500
|
24
|
2200
|
380
|
||||||||
|
MPH-425
|
-
|
-
|
G 2
|
G 1(1/2)
|
600
|
29
|
3000
|
380
|
||||||||
|
Contact with our sales for product catalog
|
|
|
|
|
|
|
|
|
||||||||
|
R represents standard type(Tube connection) RM represents Thread connection
|
|
|
|
|
|
|
|
|
||||||||
|
RZ represents higher head type RX represents High flow type
|
|
|
|
|
|
|
|
|
||||||||
|
N represents revised type, detailed parameter refer to table above or consult with our sales
|
|
|
|
|
|
|
|
|
||||||||
