- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
2200/850/1450mm
-
Weight:
-
600 KG
-
Product name:
-
Towable Backhoe
-
COLOR:
-
Black
-
After-sales Service Provided:
-
online
-
Engine:
-
None, drive by tractor PTO
-
Type:
-
rear excavator
-
Keywords:
-
Backhole
-
Bucket Capacity:
-
0.03-0.07 M3
-
Installation position:
-
behind tractor
-
Purpose:
-
Earth Excavation
-
Delivery time:
-
3-5 Days
Quick Details
-
Application:
-
Garden / Farm work
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
yueshan
-
Dimension(L*W*H):
-
2200/850/1450mm
-
Weight:
-
600 KG
-
Product name:
-
Towable Backhoe
-
COLOR:
-
Black
-
After-sales Service Provided:
-
online
-
Engine:
-
None, drive by tractor PTO
-
Type:
-
rear excavator
-
Keywords:
-
Backhole
-
Bucket Capacity:
-
0.03-0.07 M3
-
Installation position:
-
behind tractor
-
Purpose:
-
Earth Excavation
-
Delivery time:
-
3-5 Days
Products Description
|
Model
|
YSTT-6
|
YSTT-7
|
YSTT-8
|
YSTT-9
|
YSTT-10
|
YSTT-12
|
|
Matched Power
|
16-35 hp
|
25-75 hp
|
45-85hp
|
50-100 hp
|
70-125hp
|
80-150hp
|
|
Max Digging Deep
|
1850 mm
|
2150 mm
|
2640 mm
|
2900 mm
|
3000 mm
|
3500mm
|
|
Dig deep in depth
|
1600 mm
|
2000 mm
|
2500 mm
|
2760 mm
|
2800 mm
|
3350mm
|
|
Max Digging Height
|
2500 mm
|
3400 mm
|
3510 mm
|
3900 mm
|
4000 mm
|
4300mm
|
|
Max Unloading Height
|
1400 mm
|
1760 mm
|
2000 mm
|
2327mm
|
2362 mm
|
2700mm
|
|
Unload height
|
1733 mm
|
1878 mm
|
1952 mm
|
2413 mm
|
2540 mm
|
2770mm
|
|
Max Digging Radius
|
2800 mm
|
3360 mm
|
3930 mm
|
3977 mm
|
3986 mm
|
4300mm
|
|
Bucket force
|
1300 kg
|
1200 kg
|
1600 kg
|
1900 kg
|
2600 kg
|
2700mm
|
|
Digging rods digging force
|
790 kg
|
950 kg
|
1000 kg
|
1270 kg
|
1720 kg
|
1900mm
|
|
Bucket rotation angle
|
160°
|
160°
|
160°
|
150°
|
150°
|
172°
|
|
Swing Angle For Boom
|
140°
|
140°
|
140°
|
160°
|
160°
|
180°
|
|
Operating pressure
|
16 Mpa
|
16 Mpa
|
16 Mpa
|
16 Mpa
|
16 Mpa
|
16 Mpa
|
|
Bucket Width
|
300 mm
|
400 mm
|
450 mm
|
480 mm
|
500 mm
|
550 mm
|
|
Bucket Cubage
|
0.03 m3
|
0.036 m3
|
0.048 m3
|
0.054 m3
|
0.06 m3
|
0.07 m3
|
Details Images
Specifications
backhoe for farm tractors
1. match tractors from 16hp to 100hp
2. loading capacity 0.03m3 to 0.0666m3
3.Bucket sizes 10"-22"
LW Series 3 Point Hitch Backhoe for farm tractors from 15hp to 100hp
Features
* 3 Point Hitch Backhoe Specification & Features & Options:
* 3 Point fits most tractors with a Category 1 Hitch.
* Optionable Bucket sizes 10"-22" are all interchangeable.
* Options Reservoir Tank with Filter.
* PTO Pump and gear box.
* Color's are Black or Red, paint is powder coated
backhoe for farm tractors
1. match tractors from 16hp to 100hp
2. loading capacity 0.03m3 to 0.0666m3
3.Bucket sizes 10"-22"
LW Series 3 Point Hitch Backhoe for farm tractors from 15hp to 100hp
Features
* 3 Point Hitch Backhoe Specification & Features & Options:
* 3 Point fits most tractors with a Category 1 Hitch.
* Optionable Bucket sizes 10"-22" are all interchangeable.
* Options Reservoir Tank with Filter.
* PTO Pump and gear box.
* Color's are Black or Red, paint is powder coated
Packaging & Shipping
Certifications
FAQ
1.Q:What is your payment term ?
A:We accept T/T, Western Union, Paypal etc.
2.Q:Do you have CE certificate ?
A:Yes, most of our products have the CE certificate
3.Q:What is your MOQ?
A:1Sets.
4.Q:What is the product warranty period?
A:We have 12 months warranty.
Provide after-sales service support andagricultural technical support.
5.Q: Which countries do you sell mini excavators to?
A: United States, Australia, United States, Mexico, United Kingdom, Italy, Germany, France and Southeast Asia, etc.
6.Q:How to install the equipment after purchasing ?
A:We will provide professional installation video to illustrate.Also provide manual.
