- Product Details
- {{item.text}}
Quick Details
-
Dimension:
-
2450x1220x1397mm
-
Place of Origin:
-
Shanxi, China
-
Vehicle size (length*width*height):
-
2450x1220x1397mm
-
Ground clearance:
-
270mm
-
Curb weight:
-
280kg
-
Rated load capacity:
-
129kg
-
Maximum speed:
-
50km/h
-
Fuel tank capacity:
-
14L
-
Engine model:
-
Single-cylinder, liquid-cooled, 4-stroke, 4-valve, SOHC
-
Actual displacement:
-
250cc
-
Bore*stroke:
-
91*76.8mm
Quick Details
-
Displacement:
-
250cc
-
Brand Name:
-
HY
-
Tire Size:
-
Front 25*8-12/Rear 25*10-12
-
Dimension:
-
2450x1220x1397mm
-
Place of Origin:
-
Shanxi, China
-
Vehicle size (length*width*height):
-
2450x1220x1397mm
-
Ground clearance:
-
270mm
-
Curb weight:
-
280kg
-
Rated load capacity:
-
129kg
-
Maximum speed:
-
50km/h
-
Fuel tank capacity:
-
14L
-
Engine model:
-
Single-cylinder, liquid-cooled, 4-stroke, 4-valve, SOHC
-
Actual displacement:
-
250cc
-
Bore*stroke:
-
91*76.8mm
Marketing Campaign
Product Images
Product Paramenters
|
Certification
|
|
EPA approved
|
|
|
Engine type
|
|
4-stroke,Single-Cylinder, Air/Oil-cooled
|
|
|
Displacement
|
|
232cc
|
|
|
Horse Power
|
|
10.5kw(7500r/min) 14.5HP
|
|
|
Valve Configuration
|
|
OHV
|
|
|
Compression ratio
|
|
9.2:1 /10.3:1
|
|
|
Fuel Delivery System
|
|
Fuel Pump Carburetor
|
|
|
Choke System
|
|
Automatic
|
|
|
Fuel capacity
|
|
9.5L (2.1 Gallon)
|
|
|
Driveline Type
|
|
2X4
|
|
|
Final Drive
|
|
Chain-drive
|
|
|
Transmission
|
|
Constantly Variable Transmission
|
|
|
Gear Selection
|
|
Forward & Reverse Single Speed
|
|
|
Forward Lights
|
|
Headlights LED
|
|
|
Rear Lights
|
|
LED Brake Lights & Left/Right Signal lights
|
|
|
Starting system
|
|
Electric start
|
|
|
Ignition system
|
|
C.D.I
|
|
|
Suspension Front
|
|
Double A-arm optional
|
|
|
Suspension Rear
|
|
Dual Shock Swing arm
|
|
|
Brakes Front
|
|
Front Dual Hydraulic Disk
|
|
|
Brakes Rear
|
|
Rear Single Axle Hydraulic Disk
|
|
|
Front Tread
|
|
1020mm ( 40.2 in)
|
|
|
Rear Tread
|
|
1000mm ( 39.0in)
|
|
|
Front & Rear tire size
|
|
22x8-10 / 22x10-10
|
|
|
Loading information
|
|
8 units/20″; 18units/40″; 26units/40HQ
|
|
|
Manufacturers Defect Warranty
|
|
6 Months
|
|
|
Top speed
|
|
50km/h
|
|
|
Dry weight
|
|
245kg ( 540 lbs.)
|
|
|
Gross weight
|
|
280kgs(617lbs)
|
|
|
Wheelbase
|
|
1885mm (74.2in)
|
|
|
Vehicle dimension (L×W×H)
|
|
2450x1220x1397mm ( 96.5x 48.0x55.0 in)
|
|
|
Packing size
|
|
2290x1300x815mm (90.2x51.2x32.1in)
|
|
|
Ground clearance
|
|
152mm (6in)
|
|
|
Safety
|
|
Driver & Passenger Seat belts/ Driver and Passenger Steel half door.
|
|
